The Schneider Electric TM172PDG42R is a Modicon M172 Performance programmable logic controller with integrated display and 42 I/O points. Designed specifically for HVAC and pumping control applications, this controller features 12 digital inputs, 12 digital outputs with relay configuration options, 12 analog inputs, and 6 analog outputs. The unit includes a 128x64 pixel backlit LCD display for local monitoring and control. It supports multiple communication protocols including Modbus TCP/IP via Ethernet, Modbus Serial via dual RS485 ports, and BACnet IP/MS-TP, making it ideal for building automation and industrial control systems. The controller offers flexible programming via SoMachine HVAC software compliant with IEC 61131-3 standards. Expansion capabilities are provided through a CAN expansion bus port, allowing system scalability as application requirements grow.
Item Details
- Brand Name: Schneider Electric
- Manufacturer: Schneider Electric
- Item Type Name: Programmable Logic Controller
- Product Family / Series: Modicon M171/M172
- Model Variant: Performance Display
- Alternate Brand: Square D By Schneider Electric
Product Specifications
- total_io_points: 42
- digital_inputs: 12
- digital_outputs: 12 relay outputs
- analog_inputs: 12
- analog_outputs: 6
- power_supply: 24 V AC/DC
- sensor_power_supply_5v: 5 V DC at 50 mA
- sensor_power_supply_24v: 24 V DC at 150 mA
- display: 128x64 pixel backlit LCD
- communication_ports: 2x RS485, 1x Ethernet RJ45, 1x CAN port, 1x USB Type A, 1x USB Mini-B
- communication_protocols: Modbus TCP, Modbus Serial, BACnet IP, BACnet MS/TP
- programming_software: SoMachine HVAC
- programming_standard: IEC 61131-3
- operating_temperature: -20 to 60 °C
- pwm_capability: AO3, AO4 up to 2 kHz
- expansion_bus: CAN expansion bus
- ip_rating: IP20
Additional Details
- Certifications / Approvals: RoHS
- Mounting Type: DIN rail or panel mount
- Rohs Compliant: Yes
- Application Focus: HVAC and pumping control solutions
- Green Premium: Yes
Measurements
- Mounting Temperature Derating: Maximum 60 °C ambient when mounted horizontally upward
