| Characteristic | Value(s) |
|---|---|
| Rated operational voltage limits | 19.2...26.4 V DC |
| [Ui] rated insulation voltage | 250 V conforming to IEC |
| Maximum switching voltage | 250 V AC 28 V DC |
| Drop-out voltage threshold | >= 0.1 Uc DC |
| Load current | 3 A at 250 V AC 3 A at 28 V DC |
| Maximum switching capacity | 750 VA AC 84 W DC |
| Average resistance | 640 Ohm at 23 °C +/- 10 % |
| Average coil consumption | 0.9 W, DC |
| Mechanical durability | 10000000 cycles |
| Electrical durability | 100000 cycles for resistive load |
| Safety reliability data | B10d = 100000 |
| Operating rate | <= 1200 cycles/hour under load <= 18000 cycles/hour no-load |
| Utilisation coefficient | 20 % |
| Dielectric strength | 2000 V AC between coil and contact with basic insulation 2000 V AC between poles with basic insulation 1000 V AC between contacts with micro disconnection |
| Protection category | RT I |
| pollution degree | 2 |
| Operating position | Any position |
| Test levels | Level A group mounting |
| Sale per indivisible quantity | 10 |
| Contacts material | Silver alloy (Ag/Ni) |
| Product weight | 0.034 kg |
