The GT2103-PMBDS is a compact graphic operation terminal from Mitsubishi Electric's GOT2000 series, designed for industrial human-machine interface applications. This GT21 model features a 3.8-inch TFT monochrome display with 320x128 pixel resolution and 32 grayscale levels, enhanced by a 5-color LED backlight (white, green, red, orange, pink). The device incorporates an analog resistive film touch panel digitizer for user input. With IP67F front panel protection, it is suitable for demanding industrial environments. The HMI includes multiple communication interfaces including Ethernet, USB, RS-232, and RS-422/485, supporting MODBUS protocol for connectivity with PLCs and other automation equipment. Internal memory capacity of 3 MB ROM provides storage for operational data and configurations, with SD card slot expansion available for additional storage needs.
Item Details
- Brand Name: Mitsubishi
- Manufacturer: Mitsubishi Electric
- Item Type Name: Human Machine Interface (HMI)
- Product Family / Series: GOT2000 Series
- Model Type: GT21
Product Specifications
- display_type: TFT monochrome LCD
- display_size: 3.8 inch
- resolution: 320 x 128 pixels
- display_colors: Monochrome (32 grayscale)
- backlight: 5-color LED (white/green/red/orange/pink)
- display_area: 89.0 x 35.6 mm
- touch_panel_type: Analog resistive film
- touch_panel_life: 100,000 touches (with stylus)
- internal_memory: 3 MB ROM
- memory_card_slot: SD card
- usb_ports: 1
- rs232_ports: 1
- rs422_485_ports: 1
- network_options: Ethernet, MODBUS
- power_supply: 24 V DC (+10%, -15%)
- power_consumption: 1.9 W or less
- protection_class: IP67F (front panel)
- operating_temperature: 0 to +55 °C
- backlight_life: 50,000 hours (at 25°C, 50% intensity)
- battery_life: Approx. 5 years (at 25°C)
- display_intensity_adjustment: 32-level
Additional Details
- Lifecycle Status: Available from Stock
- Frame Color: Black
Measurements
- Weight: 0.2 kg
- Width: 113 mm
- Height: 74 mm
- Depth: 27 mm
