The GP-4201TW is a compact 3.5-inch HMI touchscreen panel from Pro-face's GP-4000 series, designed for industrial automation applications requiring operator interface capabilities in space-constrained installations. This unit features a TFT color LCD display with 320 x 240 pixel QVGA resolution and analog resistive touch panel technology, supporting 65,536 no-blink colors and 16,384 blink colors for clear visualization of process data and control elements. The device is programmed using GP-Pro EX software and offers dual serial communication interfaces: COM1 with RS-232C and COM2 with RS-422/485, along with USB Type-A and mini-B ports and an SD card slot for data logging and program transfer. Notable features include a non-replaceable white LED backlight rated for 50,000+ hours with eight adjustable brightness levels, rechargeable battery for clock backup, and 8 MB flash memory for screen data storage. The GP-4201TW does not include Ethernet connectivity, distinguishing it from other models in the GP-4000 series. It is suitable for machine control panels, process monitoring, and equipment interface applications where compact size and reliable touch operation are essential.
Item Details
- Brand Name: Pro-face
- Manufacturer: Pro-face by Schneider Electric
- Item Type Name: Human Machine Interface Touchscreen Display
- Product Family / Series: GP-4000 Series
- Model Number: GP-4201TW
- Global Code: PFXGP4201TADW
Product Specifications
- display_type: TFT Color LCD
- display_size: 3.5 inches
- resolution: 320 x 240 pixels (QVGA)
- display_colors_no_blink: 65,536 colors
- display_colors_blink: 16,384 colors
- backlight: White LED, non-replaceable
- backlight_life: 50,000+ hours
- backlight_brightness_levels: 8 levels
- touch_panel_type: Analog resistive
- input_voltage: 24 V DC nominal
- voltage_range: 19.2 to 28.8 V DC
- power_consumption: 9.6 W or less
- memory_flash: 8 MB (screen area)
- memory_sram: 128 KB (screen area)
- logic_program_area: 132 KB (15,000 steps)
- com1_interface: RS-232C, D-Sub 9-pin plug
- com1_speed: 2,400 to 115,200 bps
- com2_interface: RS-422/485, D-Sub 9-pin plug
- com2_speed: 2,400 to 115,200 bps, 187,500 bps (MPI)
- usb_type_a: USB 2.0, 5 V DC ±5%, 500 mA max
- usb_mini_b: USB 2.0
- sd_card_slot: Yes
- ethernet: Not available
- battery: Rechargeable battery for clock backup
- operating_temperature: 0 to 50 °C (32 to 122 °F)
- storage_temperature: -20 to 60 °C
- operating_humidity: 10 to 90% RH (non-condensing)
- storage_humidity: 10 to 90% RH (non-condensing)
- enclosure_rating: IP65f front, NEMA 4x/13 (when panel-mounted)
- pollution_degree: 2
- grounding: Functional ground, 100 Ω or less, AWG 14 or thicker
Additional Details
- Programming Software: GP-Pro EX
- Mounting Type: Panel mount
- Cooling Method: Natural air circulation
- Shock Resistance: IEC 61131-2 compliant
- Vibration Resistance: IEC 61131-2 compliant
Measurements
- Weight: 0.88 lbs (approximately 0.4 kg)
