The WTB26I-24161120A00 is a compact photoelectric proximity sensor from Sick's W26 product family, featuring background suppression technology for reliable object detection. This sensor utilizes infrared LED light at 850 nm wavelength with a point-shaped light spot for precise detection. It offers an adjustable sensing range from 30 mm to 2,000 mm, with optimal performance between 200 mm and 800 mm. The sensor features dual complementary digital outputs with push-pull PNP/NPN configuration and supports both light/dark switching modes. It incorporates IO-Link communication for advanced configuration and Smart Task functions, along with BluePilot teach-turn adjustment for easy setup. The rectangular housing design is rated IP67/IP69K for harsh industrial environments and includes LED indicators for operational status, sensing range, and object detection feedback.
Item Details
- Brand Name: Sick
- Manufacturer: Sick
- Item Type Name: Photoelectric Proximity Sensor
- Product Family / Series: W26
- Part Number: WTB26I-24161120A00
- Ordering Code: 1218667
- Housing Design: Rectangular
Product Specifications
- functional_principle: Photoelectric proximity sensor with background suppression
- sensing_range_min: 30 mm
- sensing_range_max: 2000 mm
- adjustable_switching_threshold: 180 mm to 2000 mm
- recommended_sensing_range: 200 mm to 800 mm
- light_source: LED
- light_type: Infrared
- wavelength: 850 nm
- light_spot_shape: Point-shaped
- light_spot_size_at_1000mm: Ø 14 mm
- led_service_life: 100,000 h at Ta = +25 °C
- supply_voltage: 10 V DC to 30 V DC
- current_consumption: ≤ 30 mA without load at UB = 24 V
- ripple: ≤ 5 Vpp
- output_type: Push-pull: PNP/NPN
- number_of_outputs: 2 (Complementary)
- switching_mode: Light/dark switching
- output_current_max: ≤ 100 mA
- response_time: ≤ 500 µs
- repeatability_response_time: 150 µs
- switching_frequency: 1,000 Hz
- protection_class: III
- connection_type: M12 connector, 4-pin
- adjustment_method: Teach-Turn, BluePilot, IO-Link
- communication_interface: IO-Link
Additional Details
- Protection Rating: IP67/IP69K
- Ambient Temperature Operation: -40 °C to +60 °C
- Ambient Temperature Storage: -40 °C to +75 °C
- Air Humidity: 35% to 95% relative humidity (no condensation)
- Shock Resistance: 50 g, 11 ms (EN60068-2-27)
- Vibration Resistance: 10 Hz to 2,000 Hz (EN60068-2-6)
- Emc Compliance: EN 60947-5-2
- Normative Reference: EN 62471:2008-09, IEC 62471:2006
- Led Risk Group: Free group
- Ul File Number: NRKH.E181493 & NRKH7.E181493
- Usage Category: DC-12, DC-13 (EN 60947-5-2)
- Mttfd: 629 years
- Dcavg: 0%
- Mission Time: 20 years (EN ISO 13849)
- Cleaning Agent Resistance: ECOLAB
Measurements
- Dimensions: 24.6 mm x 82.5 mm x 53.3 mm (W x H x D)
