The SICK WL12G-3O2431 is a compact retroreflective photoelectric sensor from the W12G series, designed for reliable detection of objects including transparent materials in industrial automation applications. This sensor utilizes autocollimation principle with polarization filters to detect objects at distances up to 4 meters when used with the PL80A reflector. It features visible red LED light source operating at 640 nm wavelength and provides selectable light/dark switching modes via control wire. The sensor is equipped with an 11-turn potentiometer for precise sensitivity adjustment and offers fast response time of 330 microseconds with switching frequency up to 1500 Hz. Its robust metal housing is rated IP66/IP67/IP69K for harsh industrial environments, and it operates across a wide temperature range from -40°C to +60°C, making it suitable for conveyor systems, material handling, assembly lines, robotics, and automated machinery applications.
Item Details
- Brand Name: Sick
- Manufacturer: SICK
- Item Type Name: Retroreflective Photoelectric Sensor
- Product Family / Series: W12G
- Part Number: WL12G-3O2431
- Order Code: 1041457
Product Specifications
- sensing_principle: Photoelectric retro-reflective sensor (autocollimation)
- sensing_range: 0 m to 4 m
- light_source: Visible red LED
- wavelength: 640 nm
- light_spot_size: Ø 25 mm at 1.5 m
- supply_voltage: 10 V DC to 30 V DC
- current_consumption: 30 mA
- output_type: PNP
- switching_mode: Light/dark switching (selectable via L/D control wire)
- output_current_max: 100 mA
- response_time: ≤ 330 µs
- switching_frequency: 1500 Hz
- connection_type: Male connector M12, 4-pin
- adjustment: Potentiometer, 11 turns
- angle_of_dispersion: Approx. 1.5°
- polarisation_filters: Yes
- protection_class: III
- enclosure_rating: IP66, IP67, IP69K
- special_feature: Detecting transparent objects
- circuit_protection: Reverse polarity, interference pulse suppression, overload and short-circuit protection
- operating_temperature: -40 °C to +60 °C
- storage_temperature: -40 °C to +75 °C
Additional Details
- Country of Origin*: Germany
- Items Supplied: 2x clamps BEF-KH-W12 with screws
- Recommended Reflector: PL80A
- Led Service Life: 100,000 h at +25 °C
- Mttfd: 823 years
- Ul File Number: NRKH.E181493 & NRKH7.E181493
*Country of origin may vary.
Measurements
- Weight: 120 g
- Dimensions: 15.6 mm x 48.5 mm x 42 mm (W x H x D)
- Housing Material: Metal
