The Delta VFD007E43T is a sensorless vector AC micro drive from the VFD-E series, designed for precision motor speed control in industrial applications. This compact drive features a power rating of 0.75 kW (1 HP) with a three-phase 460V input, delivering an output capacity of 2 kVA at 2.5A rated current. Built with IP20 enclosure rating and natural air cooling, the drive incorporates SPWM control with V/f or sensorless vector operation modes. Key features include a built-in PLC function for executing ladder logic programs, built-in dynamic brake chopper, MODBUS protocol via RS-485, and modular design supporting optional extension cards for I/O, relays, encoders, and fieldbus modules including Profibus, DeviceNet, and CANopen. The drive offers 150% overload capacity for 1 minute, adjustable output frequency from 0.1 to 600 Hz, auto-torque and slip compensation, and comprehensive protection functions including over-voltage, over-current, and thermal overload.
Item Details
- Brand Name: Delta
- Manufacturer: Delta Electronics
- Item Type Name: Variable Frequency Drive
- Product Family / Series: VFD-E Series
- Frame Size: A1
- Model Number: VFD007E43T
Product Specifications
- power_rating: 0.75 kW (1 HP)
- input_voltage: 460V three-phase
- input_voltage_range: 380 to 480V AC
- input_frequency: 50/60 Hz
- output_capacity: 2 kVA
- output_current: 2.5 A
- output_frequency_range: 0.1 to 600 Hz
- maximum_carrier_frequency: 15 kHz
- control_method: SPWM (Sinusoidal Pulse Width Modulation)
- control_mode: V/f or Sensorless Vector (Open Loop)
- starting_torque: 150% at 3.0 Hz
- overload_capacity: 150% of rated current for 1 minute
- braking_type: DC Injection, Dynamic Braking (Built-in Brake Chopper)
- communication_protocol: MODBUS via RS-485
- enclosure_rating: IP20
- cooling_method: Natural air cooling
- operating_temperature: -10 to +50°C
- acceleration_deceleration_time: 0.1 to 600 seconds
Additional Details
- Certifications / Approvals: UL, cUL listed
- Built In Features: Built-in PLC function, Built-in EMI Filter, LED status indicator
- Optional Modules: Profibus, DeviceNet, LonWorks, CANopen, I/O card, Relay card, PG (Encoder) card, USB card
- Protection Functions: Over-voltage, over-current, under-voltage, overload, ground fault, overheating, electronic thermal, IGBT short circuit
- Mounting Options: Optional DIN rail adapter available
Measurements
- Weight: 1.2 kg
- Dimensions: 72 x 142 x 152 mm (W x H x D)
