The SGMGV-75D3A61 is a rotary brushless AC servo motor from Yaskawa's Sigma-5 series, designed for medium capacity industrial automation applications. This high-torque servo motor features a center-tapped keyed shaft with a built-in 20-bit absolute encoder for precise position feedback and control. Rated at 7.5 kW output power with 48 Nm continuous torque and capable of 119 Nm instantaneous peak torque, this motor operates at 400 VAC and delivers reliable performance at rated speeds up to 1500 rpm and maximum speeds of 3000 rpm. The motor incorporates IP67 protective structure for harsh industrial environments and utilizes a 180x180 mm flange mounting configuration. It is designed for counter-clockwise rotation when viewed from the load side and requires operation with SGDV servo drives. This model is part of Yaskawa's legacy product line and is still available for purchase but not promoted for new applications.
Item Details
- Brand Name: Yaskawa
- Manufacturer: Yaskawa Electric Corporation
- Item Type Name: AC Servo Motor
- Product Family / Series: Sigma-5 SGMGV Series
- Model Designation: SGMGV-75D3A61
- Motor Type: Rotary brushless AC servo motor
- Design Revision: A (Standard)
- Shaft Type: Center-tapped keyed shaft with tap
- Rotation Direction: Counter-clockwise (CCW) with forward run reference when viewed from load side
Product Specifications
- rated_output_power: 7.5 kW
- supply_voltage: 400 V AC
- rated_current: 25.7 A
- instantaneous_max_current: 65 A
- rated_torque: 48 Nm
- torque_constant: 1.92 Nm/A (RMS)
- instantaneous_peak_torque: 119 Nm
- rated_speed: 1500 rpm
- maximum_speed: 3000 rpm
- encoder_type: 20-bit Absolute Serial Encoder
- encoder_resolution: 20-bit
- moment_of_inertia: 0.000125 kg·m² (1.25 kg·cm²)
- mounting_flange: 180 x 180 mm
- protective_structure: IP67
- compatible_servo_drives: SGDV Series Servopacks
- insulation_resistance: 10 MΩ minimum at 500 V DC
Additional Details
- Lifecycle Status: Legacy product - still available but not promoted for new applications
- Cooling Requirements: 550 mm x 550 mm x 30 mm iron heat sink for rated specifications
- Operating Temperature Reference: Specifications at 20°C armature winding temperature
