The Yaskawa SGMAV-08A3A61 is a compact brushless AC servo motor from the Sigma-5 series, designed for demanding industrial automation applications. This motor delivers 750 W rated power with a rated torque of 2.39 Nm at 3000 rpm. It features a 20-bit absolute encoder for precise position feedback and a straight shaft with key and tap for secure mechanical coupling. Operating at 200 VAC three-phase power with a rated current of 5.3 A, the motor offers a speed range of 3000-6000 rpm. It provides high instantaneous peak torque of 7.16 Nm for dynamic motion requirements. The flange-mounted motor is compatible with Yaskawa SGDV series servo drives and is suited for semiconductor equipment, chip mounters, PCB drilling stations, robotics, material handling machines, and food processing equipment. The SGMAV series emphasizes super high power rate and instantaneous peak torque capabilities.
Item Details
- Brand Name: Yaskawa
- Manufacturer: Yaskawa Electric Corporation
- Item Type Name: AC Servo Motor
- Product Family / Series: Sigma-5 SGMAV Series
- Model Number: SGMAV-08A3A61
- Mounting Type: Flange Mount
- Shaft Type: Straight Shaft with Key and Tap
- Brake Option: Without Brake
- Encoder Type: 20-bit Absolute Encoder
Product Specifications
- rated_power: 750 W
- rated_torque: 2.39 Nm
- peak_torque: 7.16 Nm
- rated_speed: 3000 rpm
- maximum_speed: 6000 rpm
- voltage: 200 VAC
- phases: 3 Phase
- rated_current: 5.3 A
- encoder_resolution: 20 bit
- compatible_drives: SGDV-5R5A@1A
Additional Details
- Lifecycle Status: Legacy (not recommended for new designs)
- Protection Rating: IP67 (connectors and cables)
Measurements
- Weight: 2.5 kg
