The Yaskawa SGDV-180A11A002000 is a high-performance AC servo drive from the Sigma-5 series, designed for demanding industrial automation applications requiring precise motion control. This SERVOPACK utilizes MECHATROLINK-II communication interface for rotary servo motors, enabling real-time communication at up to 10 Mbps with cycle times from 250 microseconds to 4 milliseconds. The drive features advanced control capabilities including torque, position, and speed control modes with high-precision positioning through five-stage notch filtering for vibration suppression. It supports natural cooling and includes integrated safety functions equivalent to STO (Safe Torque Off) per IEC61800-5-2. The unit is engineered for applications demanding frequent high-speed, high-precision positioning and offers automatic motor identification and online tuning capabilities.
Item Details
- Brand Name: Yaskawa
- Manufacturer: Yaskawa Electric Corporation
- Item Type Name: AC Servo Drive
- Product Family / Series: Sigma-5 SGDV Series
- Model Designation: SGDV-180A11A002000
- Series: Sigma-V
- Communication Interface: MECHATROLINK-II
- Encoder Type: 17-bit absolute value serial encoder
- Cooling Method: Natural cooling
- Design Revision: A
Product Specifications
- rated_power: 2.0 kW
- continuous_output_current: 18.5 A
- input_voltage: 170-253 V AC
- nominal_voltage: 200 V AC / 208 V AC / 220 V AC / 230 V AC / 240 V AC
- voltage_tolerance: +10% / -15%
- input_phases: 3-phase
- frequency: 50/60 Hz
- maximum_motor_capacity: 15 kW
- control_modes: Torque, Position, Speed, Pressure feedback
- speed_control_range: 1:5000
- communication_speed: 10 Mbps maximum
- communication_cycle: 250 µs to 4 ms
- max_stations: 30
- safety_function: STO (Safe Torque Off) per IEC61800-5-2
- notch_filter_stages: 5
Additional Details
- Certifications / Approvals: IEC61800-5-2 compliant
- Mounting Type: Base mounting (standard)
- Control Interface: Analog voltage / Pulse train
- Servo Feedback: Absolute position detection
