The Omron R88D-GP08H is a compact SmartStep 2 AC servo drive designed for pulse input control applications. This single-phase servo drive delivers 750 W of power and operates on 200 VAC supply voltage with a range of 170-264 VAC at 50/60 Hz. It features online auto-tuning for simplified setup, adaptive filters for vibration and resonance suppression, electronic gearing, four internal speed settings, and dual torque limit functions. The drive supports position control via pulse input and includes a built-in regenerative resistor with capability for external resistor connection. Designed for compact installation at 48% of the footprint compared to the previous SmartStep series, the R88D-GP08H is compatible with Omron G-Series servo motors and can be configured using CX Drive software. It is suitable for factory automation, positioning systems, and machine control applications requiring precise motion control.
Item Details
- Brand Name: Omron
- Manufacturer: Omron Industrial Automation
- Item Type Name: AC Servo Drive
- Product Family / Series: SmartStep 2 G-Series
- Control Type: Pulse input control
Product Specifications
- power_rating: 750 W
- supply_voltage: 170-264 V AC
- nominal_voltage: 200 V AC
- phases: Single phase
- supply_frequency: 50/60 Hz
- output_current_max: 4 A
- operating_temperature: 0 to 55 °C
- storage_temperature: -20 to 65 °C
- humidity: 90% max (no condensation)
- vibration_resistance: 10 to 60 Hz, 5.9 m/s² max
- shock_resistance: 19.6 m/s² max, 3 times each in X, Y, Z directions
- insulation_resistance: 0.5 MΩ min at 500 V DC
- enclosure_rating: IP10 (built into panel)
Additional Details
- Country of Origin*: China
- Certifications / Approvals: UL 508C, cUL C22.2 No. 14, EN55011 Class A Group 1, EN 61000-6-2, EN50178
- Rohs Compliant: Yes
*Country of origin may vary.
Measurements
- Weight: 1872 g
- Package Dimensions: 239 x 217 x 119 mm
