The IFM PI7993 is a flush-mount pressure sensor with an integrated 4-digit alphanumeric display designed for precision pressure monitoring in industrial automation and fluid control applications. This electronic pressure sensor features a ceramic measuring element with no dead space, making it suitable for hygienic and demanding environments. The device offers two programmable switching outputs (PNP/NPN) that can be configured as normally open or normally closed, with adjustable set points, hysteresis, and damping parameters. Its freely rotatable housing (350°) and intuitive display allow for flexible installation and easy on-site parameter adjustment. The sensor provides excellent accuracy with linearity and hysteresis deviations below ±0.15% of span, along with integrated diagnostics, reverse polarity protection, and overload protection for reliable operation in harsh industrial conditions.
Item Details
- Brand Name: IFM
- Manufacturer: ifm electronic gmbh
- Item Type Name: Flush Pressure Sensor with Display
- Product Family / Series: PI Series Pressure Sensors
- Full Part Number: PI-025-REB34-QFRKG/US/ /P
Product Specifications
- measuring_range: -1 to 25 bar (-14.4 to 362.7 psi, -0.1 to 2.5 MPa)
- operating_voltage: 18 to 32 V DC
- output_type: PNP/NPN switching outputs (programmable)
- number_of_outputs: 2 digital switching outputs
- switching_frequency: 85 Hz
- output_current: 250 mA permanent
- voltage_drop: ≤ 2 V DC
- response_time: < 6 ms
- accuracy_linearity: < ±0.15% of span (1:1 turndown)
- accuracy_hysteresis: < ±0.15% of span (1:1 turndown)
- long_term_stability: < ±0.1% of span per year
- temperature_coefficient_zero: < ±0.05% of span per 10 K (0 to 70°C)
- temperature_coefficient_span: < ±0.15% of span per 10 K (0 to 70°C)
- set_point_range: -0.96 to 25 bar (adjustable in 0.02 bar steps)
- insulation_resistance: 100 MΩ minimum at 500 V DC
- protection_class: III
- display: 4-digit alphanumeric, rotatable
- housing_rotation: 350° freely rotatable
- process_connection: Flush mount (no dead space)
- ambient_temperature: -25 to 80°C
- storage_temperature: -40 to 100°C
- reverse_polarity_protection: Yes
- short_circuit_protection: Yes (pulsed)
- overload_protection: Yes
- power_on_delay: 0.5 s
- integrated_watchdog: Yes
Additional Details
- Materials Housing: Stainless steel 1.4404/316L, PC, PBT, PEI, FKM, PTFE
- Materials Wetted Parts: Ceramic (99.9% Al2O3), Stainless steel 1.4435/316L
- Surface Finish: Ra < 0.4 / Rz
- Programmable Parameters: Hysteresis/window, normally open/closed, switching logic, damping (0-100s), display rotation and on/off, display units, zero and span adjustment
