Keyence

NR-XTH08T Keyence

Specifications

Model				NR-XTH08T
Input method				Insulated single-end input, channels insulated from each other, input channels insulated from the case and other units (system)
Number of input channels				8^*1
Input connector type				Miniature thermocouple connector (Universal type)
Measurement cycle				Maximum sampling cycle: 10 ms (100 Hz) to 1 h
A/D converting system				Delta-sigma method
A/D resolution				24 bits
A/D integration time (noise filter)				AUTO (Automatic configuration according to sampling cycle), 2.5 ms (400 Hz), 16.7 ms (60 Hz), 20 ms (50 Hz), 100 ms (10 Hz)
Input type				Thermocouple: K, J, E, T, R, S, B, N, C
Low pass filter				PASS / 200 Hz / 20 Hz
Averaging				Switchable between ON/OFF, Averaging rate: 2 to 128 (moving average)
Reference contact compensation				Switchable between internal and external
Reference contact compensation accuracy				±0.5°C ±0.9°F (23°C ±3°C 73.4°F ±5.4°F at input terminal temperature equilibrium)
Maximum input rating				±30 V^*2
Maximum allowable input ground voltage				Dry locations: 30 VAC and 42.4 Vpeak, or 60 VDC Wet locations: 16 VAC and 22.6 Vpeak, or 35 VDC
Withstand voltage				Between measurement input terminal and case/other units (system): 1000 VAC (50 Hz / 60 Hz) for 1 minute Between measurement input terminals: 1000 VAC (50 Hz / 60 Hz) for 1 minute
Input impedance				10 MΩ or more
Input signal source resistance				2 kΩ or less
Thermocouple burnout detection				Switchable between ON/OFF, When ON: Approx. 10 μA current detection^*3
Measurable range				K: −100 to +1372°C -148°F to +2501.6°F, −200 to −100°C -328°F to -148°F J: −100 to +1200°C -148°F to +2192°F, −200 to −100°C -328°F to -148°F E: −100 to +1000°C -148°F to +1832°F, −200 to −100°C -328°F to -148°F T: −100 to +400°C -148°F to +752°F, −200 to −100°C -328°F to -148°F N: −100 to +1300°C -148°F to +2372°F, −200 to −100°C -328°F to -148°F C: 1500 to 2315°C 2732°F to 4199°F, 0 to 1500°C 32°F to 2732°F R: 300 to 1768°C 572°F to 3214.4°F, 0 to 300°C 32°F to 572°F S: 300 to 1768°C 572°F to 3214.4°F, 0 to 300°C 32°F to 572°F B: 400 to 600°C 752°F to 1112°F, 600 to 1820°C 1112°F to 3308°F
Measurement accuracy				K: ±0.04% of rdg ±0.4°C ±0.7°F, ±0.43% of rdg ±0.1°C ±0.2°F J: ±0.03% of rdg ±0.3°C ±0.5°F, ±0.30% of rdg ±0.1°C ±0.2°F E: ±0.03% of rdg ±0.3°C ±0.5°F, ±0.27% of rdg ±0.1°C ±0.2°F T: ±0.4°C ±0.7°F, ±0.34% of rdg ±0.1°C ±0.2°F N: ±0.02% of rdg ±0.6°C ±2.1°F, ±0.63% of rdg ±0.1°C ±0.2°F C: ±0.10% of rdg ±0.2°C ±0.4°F, ±0.04% of rdg ±0.8°C ±1.4°F R: ±0.01% of rdg ±1.2°C ±2.2°F, ±2.0°C ±3.6°F S: ±0.02% of rdg ±1.2°C ±2.2°F, ±2.0°C ±3.6°F B: ±2.2°C ±4.0°F, ±1.6°C ±2.9°F ^*4
Display resolution				K: 0.05°C 0.09°F J: 0.05°C 0.09°F E: 0.05°C 0.09°F T: 0.01°C 0.02°F N: 0.05°C 0.09°F C: 0.05°C 0.09°F R: 0.05°C 0.09°F S: 0.05°C 0.09°F B: 0.05°C 0.09°F
Buffer memory				16M data^*5
Warm up time				30 minutes or more
Common mode noise reduction ratio				135 dB or more (up to 60 Hz DC) (typ.) ^*4
Remote connection				Dedicated environment-resistant remote unit input port × 1 (Remote IN), output port × 1 (Remote OUT) Connection to NR-X100W master data collection unit or other NR-XR01 remote units using environment-resistant unit cable Connectable to multiple environment-resistant measurement units^*6
Synchronization accuracy between remote connection units				±1 μs^*7
Power supply				Supplied from NR-X100W master unit
Power consumption				5.0 W max.
Surrounding air temperature				−40 to +85°C -40°F to +185°F^*8
Operating ambient humidity				Max. 100% RH^*9
Vibration resistance				100 m/s² 328.1 ft/s²; 5 to 2000 Hz; 2 hours in each of the X, Y, and Z directions (IEC 60068-2-6)^*10 Equivalent to JIS D1601 Stage 45 (Class 1, Class 2, and Class 3; equivalent to Class B) automotive vibration standard
Shock resistance				1000 m/s² 3280.8 ft/s²; 3 times in each of the X, Y, and Z directions (18 times in total) (IEC 60068-2-27)
Enclosure rating				IP65/IP67 (IEC 60529) Enclosure Type 4X (UL 50E, CSA C22.2 No. 94.2, NEMA 250) Indoor/outdoor use
Material				Main unit case: Aluminum die-casting (coated) / PBT+PC / PC, Display: Reinforced glass, Connectors: Brass (chromate processing), Connector protection cap: PBT+PC
Weight				Approx. 660 g 23.30 oz
^1 Max. expansion: 64 ch (with 8 units connected, using NR-X100W) ^2 Protection rating against temporary overvoltage. Do not apply voltage directly from an external source. ^3 The time until detection is confirmed varies depending on the acquisition setting and the input signal source resistance. Detection may be disabled depending on the low-pass filter and sampling cycle settings. For details, see P. 5–29. ^4 Does not include reference junction compensation accuracy. Specified with an A/D integration time of 20 ms (50 Hz) / 16.7 ms (60 Hz), the low-pass filter set to PASS, averaging set to 2 times, and after the warm-up time has passed and the temperature has stabilized (23°C ±3°C 73.4°F ±5.4°F). ^5 The buffer memory that can be used by the entire system is limited by the NR-X100W buffer memory. ^6 Environment-resistant unit cables can be extended by connecting an environment-resistant unit extension cable. The total length of cables used in the system should be no more than 100 m 32.8'. The distance between the NR-X100W (or NR-XR01) and environment-resistant measurement units or between environment-resistant remote measurement units should be no more than 60 m 196.9'. ^7 The sampling cycle and timing vary depending on the various measurement units used in the system. ^8 Install the product on the specified mounting sheet metal (OP-88613) for use with ambient temperatures of 80°C 176°F or higher. ^9 Use the product under the condition that the absolute humidity is 85°C 185°F with 90% RH or less. Avoid sudden temperature and humidity changes to prevent significant condensation and freezing. ^10 Testing with a 50 mm 1.97" p-p displacement limit used for 5 to 10 Hz.

$3,549.99

1-year warranty

FREE WORDWIDE SHIPPING

Est. delivery between and

Condition:

Sealed Surplus

SKU: NR-XTH08T-Sealed

Sold out

$0.00

Never Used Surplus

SKU: NR-XTH08T

1 verified stock

$3,549.99

Used

SKU: NR-XTH08T-Used

Sold out

$0.00

Variant

Quantity:

Need More?

Specifications

Model				NR-XTH08T
Input method				Insulated single-end input, channels insulated from each other, input channels insulated from the case and other units (system)
Number of input channels				8^*1
Input connector type				Miniature thermocouple connector (Universal type)
Measurement cycle				Maximum sampling cycle: 10 ms (100 Hz) to 1 h
A/D converting system				Delta-sigma method
A/D resolution				24 bits
A/D integration time (noise filter)				AUTO (Automatic configuration according to sampling cycle), 2.5 ms (400 Hz), 16.7 ms (60 Hz), 20 ms (50 Hz), 100 ms (10 Hz)
Input type				Thermocouple: K, J, E, T, R, S, B, N, C
Low pass filter				PASS / 200 Hz / 20 Hz
Averaging				Switchable between ON/OFF, Averaging rate: 2 to 128 (moving average)
Reference contact compensation				Switchable between internal and external
Reference contact compensation accuracy				±0.5°C ±0.9°F (23°C ±3°C 73.4°F ±5.4°F at input terminal temperature equilibrium)
Maximum input rating				±30 V^*2
Maximum allowable input ground voltage				Dry locations: 30 VAC and 42.4 Vpeak, or 60 VDC Wet locations: 16 VAC and 22.6 Vpeak, or 35 VDC
Withstand voltage				Between measurement input terminal and case/other units (system): 1000 VAC (50 Hz / 60 Hz) for 1 minute Between measurement input terminals: 1000 VAC (50 Hz / 60 Hz) for 1 minute
Input impedance				10 MΩ or more
Input signal source resistance				2 kΩ or less
Thermocouple burnout detection				Switchable between ON/OFF, When ON: Approx. 10 μA current detection^*3
Measurable range				K: −100 to +1372°C -148°F to +2501.6°F, −200 to −100°C -328°F to -148°F J: −100 to +1200°C -148°F to +2192°F, −200 to −100°C -328°F to -148°F E: −100 to +1000°C -148°F to +1832°F, −200 to −100°C -328°F to -148°F T: −100 to +400°C -148°F to +752°F, −200 to −100°C -328°F to -148°F N: −100 to +1300°C -148°F to +2372°F, −200 to −100°C -328°F to -148°F C: 1500 to 2315°C 2732°F to 4199°F, 0 to 1500°C 32°F to 2732°F R: 300 to 1768°C 572°F to 3214.4°F, 0 to 300°C 32°F to 572°F S: 300 to 1768°C 572°F to 3214.4°F, 0 to 300°C 32°F to 572°F B: 400 to 600°C 752°F to 1112°F, 600 to 1820°C 1112°F to 3308°F
Measurement accuracy				K: ±0.04% of rdg ±0.4°C ±0.7°F, ±0.43% of rdg ±0.1°C ±0.2°F J: ±0.03% of rdg ±0.3°C ±0.5°F, ±0.30% of rdg ±0.1°C ±0.2°F E: ±0.03% of rdg ±0.3°C ±0.5°F, ±0.27% of rdg ±0.1°C ±0.2°F T: ±0.4°C ±0.7°F, ±0.34% of rdg ±0.1°C ±0.2°F N: ±0.02% of rdg ±0.6°C ±2.1°F, ±0.63% of rdg ±0.1°C ±0.2°F C: ±0.10% of rdg ±0.2°C ±0.4°F, ±0.04% of rdg ±0.8°C ±1.4°F R: ±0.01% of rdg ±1.2°C ±2.2°F, ±2.0°C ±3.6°F S: ±0.02% of rdg ±1.2°C ±2.2°F, ±2.0°C ±3.6°F B: ±2.2°C ±4.0°F, ±1.6°C ±2.9°F ^*4
Display resolution				K: 0.05°C 0.09°F J: 0.05°C 0.09°F E: 0.05°C 0.09°F T: 0.01°C 0.02°F N: 0.05°C 0.09°F C: 0.05°C 0.09°F R: 0.05°C 0.09°F S: 0.05°C 0.09°F B: 0.05°C 0.09°F
Buffer memory				16M data^*5
Warm up time				30 minutes or more
Common mode noise reduction ratio				135 dB or more (up to 60 Hz DC) (typ.) ^*4
Remote connection				Dedicated environment-resistant remote unit input port × 1 (Remote IN), output port × 1 (Remote OUT) Connection to NR-X100W master data collection unit or other NR-XR01 remote units using environment-resistant unit cable Connectable to multiple environment-resistant measurement units^*6
Synchronization accuracy between remote connection units				±1 μs^*7
Power supply				Supplied from NR-X100W master unit
Power consumption				5.0 W max.
Surrounding air temperature				−40 to +85°C -40°F to +185°F^*8
Operating ambient humidity				Max. 100% RH^*9
Vibration resistance				100 m/s² 328.1 ft/s²; 5 to 2000 Hz; 2 hours in each of the X, Y, and Z directions (IEC 60068-2-6)^*10 Equivalent to JIS D1601 Stage 45 (Class 1, Class 2, and Class 3; equivalent to Class B) automotive vibration standard
Shock resistance				1000 m/s² 3280.8 ft/s²; 3 times in each of the X, Y, and Z directions (18 times in total) (IEC 60068-2-27)
Enclosure rating				IP65/IP67 (IEC 60529) Enclosure Type 4X (UL 50E, CSA C22.2 No. 94.2, NEMA 250) Indoor/outdoor use
Material				Main unit case: Aluminum die-casting (coated) / PBT+PC / PC, Display: Reinforced glass, Connectors: Brass (chromate processing), Connector protection cap: PBT+PC
Weight				Approx. 660 g 23.30 oz
^1 Max. expansion: 64 ch (with 8 units connected, using NR-X100W) ^2 Protection rating against temporary overvoltage. Do not apply voltage directly from an external source. ^3 The time until detection is confirmed varies depending on the acquisition setting and the input signal source resistance. Detection may be disabled depending on the low-pass filter and sampling cycle settings. For details, see P. 5–29. ^4 Does not include reference junction compensation accuracy. Specified with an A/D integration time of 20 ms (50 Hz) / 16.7 ms (60 Hz), the low-pass filter set to PASS, averaging set to 2 times, and after the warm-up time has passed and the temperature has stabilized (23°C ±3°C 73.4°F ±5.4°F). ^5 The buffer memory that can be used by the entire system is limited by the NR-X100W buffer memory. ^6 Environment-resistant unit cables can be extended by connecting an environment-resistant unit extension cable. The total length of cables used in the system should be no more than 100 m 32.8'. The distance between the NR-X100W (or NR-XR01) and environment-resistant measurement units or between environment-resistant remote measurement units should be no more than 60 m 196.9'. ^7 The sampling cycle and timing vary depending on the various measurement units used in the system. ^8 Install the product on the specified mounting sheet metal (OP-88613) for use with ambient temperatures of 80°C 176°F or higher. ^9 Use the product under the condition that the absolute humidity is 85°C 185°F with 90% RH or less. Avoid sudden temperature and humidity changes to prevent significant condensation and freezing. ^10 Testing with a 50 mm 1.97" p-p displacement limit used for 5 to 10 Hz.
