NR-FV04 Keyence

Specifications

Model		NR-FV04 ^*1
Type		Pulse measurement unit
Input method		Insulated single-end input, channels insulated from each other, input channels insulated from other units (PC)
Number of channels		4 ch ^*2
Measurement cycle		Maximum sampling cycle: 1 μs (1 MHz) to 60 s
A/D converting system		Successive approximation, simultaneous sampling of all channels
A/D resolution		14 bit
Input frequency band		250 kHz (−3 dB or more)
Low pass filter		PASS, 1.5 kHz, 15 kHz, 50 kHz
Pulse input	Input type	Pulse frequency, pulse count (Single-phase input)
	Maximum input voltage	±700 V ^*3
	Threshold voltage	+100 V, +50 V, +20 V, +10 V, +5 V, +2.5 V, +1 V, +500 mV, +250 mV, +100 mV, +50 mV, 0 V
	Minimum pulse duration	2 μs or more for both ON and OFF
	Hysteresis	AUTO, 100 mV, 500 mV, 5 V
	Pulse divisions	1 to 64 (Can be set to units of 1 division)
	Input coupling	DC rising edge, DC falling edge, AC rising edge, AC falling edge
	Digital filter	Pulse frequency: Averaging rate of 1 to 32768 (automatically selected), Pulse count: None
	Predictive functions	Predictive calculation, Stop prediction (OFF, ×1.5, ×3, ×5, ×8, ×16)
	Sensor power output	Dedicated connectors for OP-88003 (AUX POWER) × 2 when using OP-88003; +12 V, 50 mA or +5 V, 50 mA NPN open-collector output connectable, sensor power supply not insulated from system bus
Voltage input	Input type	±100 V, ±50 V, ±20 V, ±10 V, ±5 V, ±2 V
	Maximum input voltage	±700 V ^*3
	Digital filter	Averaging rate: 1 to 128 (automatically selected)
	Input coupling	DC, AC
	Common mode noise reduction ratio	80 dB or more (at up to 60 Hz DC)
	Residual noise level	0.02% of F.S., LPF: 1.5 kHz (200 μs/S, digital filter: ON); 0.05% of F.S., LPF: PASS
Measurement range	Pulse frequency	Measurable range: 0.05 to 16000.00 Hz, Display resolution: 0.01 to 1.00 Hz (selected automatically according to frequency)
	Pulse count	Measurable range: 0 to 65,000 counts/sampling cycle, Display resolution: 1 count
	±100 V	Measurable range: −110.000 to +110.000 V, Display resolution: 5 mV
	±50 V	Measurable range: −55.000 to +55.000 V, Display resolution: 2 mV
	±20 V	Measurable range: −22.000 to +22.000 V, Display resolution: 1 mV
	±10 V	Measurable range: −11.0000 to +11.0000 V, Display resolution: 0.5 mV
	±5 V	Measurable range: −5.5000 to +5.5000 V, Display resolution: 0.2 mV
	±2 V	Measurable range: −2.2000 to +2.2000 V, Display resolution: 0.1 mV
Measurement accuracy	Pulse frequency	±0.07% of rdg, ±0.01 Hz (20 Hz to 15 kHz, 20 ms/S, with digital filter ON)
	Voltage input	±0.1% of F.S., LPF: 500 Hz, with digital filter ON
Withstand voltage	Input to system bus/earth	2200 VAC (50/60 Hz) for 1 minute
Connector format		Insulated BNC connector
Input impedance		1 MΩ ±1%, approx. 30 pF
Buffer memory		16M data^*4
Warm up time		30 minutes or more
Maximum allowable voltage to ground		[When using OP-89263 1:1 voltage-resistant probe] Measurement terminal, GND terminal: 300 Vrms (CAT II); [When using OP-89264 1:1 voltage-resistant probe] Measurement terminal, GND terminal: 300 Vrms (CAT II); [When using OP-88998 10:1 voltage-resistant probe] Measurement terminal: 700 Vrms (CAT II), GND terminal: 300 Vrms (CAT II); [Direct input] Measurement terminal, GND terminal: 42.4 Vpeak and 30 Vrms, or 60 VDC ^*3
Rating	Power consumption	4 W or less (including OP-88003 sensor power supply)
Environmental resistance	Insulation resistance	500 VDC, 10 MΩ or more
	Ambient temperature	0 to +40°C 32°F to 104°F
	Relative humidity	10 to 85% RH (no condensation)
Weight		Approx. 270 g 9.53 oz
^1 The above specifications are the values when zero point adjustment is performed after the warm-up period in an environment with a temperature of 23°C ±3°C 73.4°F ±5.4°F. ^2 Max. expansion: 180 ch (with 45 units connected, using NR-X100W), 20 ch (with 5 units connected, using NR-500) ^3 At a frequency of 40 kHz or less ^4 Limited by the NR-X100W buffer memory when using the NR-X100W.

Est. delivery between and

$2,060.86

1-year warranty

FREE WORDWIDE SHIPPING

Condition:

Sealed Surplus

SKU: NR-FV04-Sealed

Sold out

$0.00

Never Used Surplus

SKU: NR-FV04

4 verified stock

$2,060.86

Used

SKU: NR-FV04-Used

1 verified stock

$1,544.45

Variant

Quantity:

Need More?

Specifications

Model		NR-FV04 ^*1
Type		Pulse measurement unit
Input method		Insulated single-end input, channels insulated from each other, input channels insulated from other units (PC)
Number of channels		4 ch ^*2
Measurement cycle		Maximum sampling cycle: 1 μs (1 MHz) to 60 s
A/D converting system		Successive approximation, simultaneous sampling of all channels
A/D resolution		14 bit
Input frequency band		250 kHz (−3 dB or more)
Low pass filter		PASS, 1.5 kHz, 15 kHz, 50 kHz
Pulse input	Input type	Pulse frequency, pulse count (Single-phase input)
	Maximum input voltage	±700 V ^*3
	Threshold voltage	+100 V, +50 V, +20 V, +10 V, +5 V, +2.5 V, +1 V, +500 mV, +250 mV, +100 mV, +50 mV, 0 V
	Minimum pulse duration	2 μs or more for both ON and OFF
	Hysteresis	AUTO, 100 mV, 500 mV, 5 V
	Pulse divisions	1 to 64 (Can be set to units of 1 division)
	Input coupling	DC rising edge, DC falling edge, AC rising edge, AC falling edge
	Digital filter	Pulse frequency: Averaging rate of 1 to 32768 (automatically selected), Pulse count: None
	Predictive functions	Predictive calculation, Stop prediction (OFF, ×1.5, ×3, ×5, ×8, ×16)
	Sensor power output	Dedicated connectors for OP-88003 (AUX POWER) × 2 when using OP-88003; +12 V, 50 mA or +5 V, 50 mA NPN open-collector output connectable, sensor power supply not insulated from system bus
Voltage input	Input type	±100 V, ±50 V, ±20 V, ±10 V, ±5 V, ±2 V
	Maximum input voltage	±700 V ^*3
	Digital filter	Averaging rate: 1 to 128 (automatically selected)
	Input coupling	DC, AC
	Common mode noise reduction ratio	80 dB or more (at up to 60 Hz DC)
	Residual noise level	0.02% of F.S., LPF: 1.5 kHz (200 μs/S, digital filter: ON); 0.05% of F.S., LPF: PASS
Measurement range	Pulse frequency	Measurable range: 0.05 to 16000.00 Hz, Display resolution: 0.01 to 1.00 Hz (selected automatically according to frequency)
	Pulse count	Measurable range: 0 to 65,000 counts/sampling cycle, Display resolution: 1 count
	±100 V	Measurable range: −110.000 to +110.000 V, Display resolution: 5 mV
	±50 V	Measurable range: −55.000 to +55.000 V, Display resolution: 2 mV
	±20 V	Measurable range: −22.000 to +22.000 V, Display resolution: 1 mV
	±10 V	Measurable range: −11.0000 to +11.0000 V, Display resolution: 0.5 mV
	±5 V	Measurable range: −5.5000 to +5.5000 V, Display resolution: 0.2 mV
	±2 V	Measurable range: −2.2000 to +2.2000 V, Display resolution: 0.1 mV
Measurement accuracy	Pulse frequency	±0.07% of rdg, ±0.01 Hz (20 Hz to 15 kHz, 20 ms/S, with digital filter ON)
	Voltage input	±0.1% of F.S., LPF: 500 Hz, with digital filter ON
Withstand voltage	Input to system bus/earth	2200 VAC (50/60 Hz) for 1 minute
Connector format		Insulated BNC connector
Input impedance		1 MΩ ±1%, approx. 30 pF
Buffer memory		16M data^*4
Warm up time		30 minutes or more
Maximum allowable voltage to ground		[When using OP-89263 1:1 voltage-resistant probe] Measurement terminal, GND terminal: 300 Vrms (CAT II); [When using OP-89264 1:1 voltage-resistant probe] Measurement terminal, GND terminal: 300 Vrms (CAT II); [When using OP-88998 10:1 voltage-resistant probe] Measurement terminal: 700 Vrms (CAT II), GND terminal: 300 Vrms (CAT II); [Direct input] Measurement terminal, GND terminal: 42.4 Vpeak and 30 Vrms, or 60 VDC ^*3
Rating	Power consumption	4 W or less (including OP-88003 sensor power supply)
Environmental resistance	Insulation resistance	500 VDC, 10 MΩ or more
	Ambient temperature	0 to +40°C 32°F to 104°F
	Relative humidity	10 to 85% RH (no condensation)
Weight		Approx. 270 g 9.53 oz
^1 The above specifications are the values when zero point adjustment is performed after the warm-up period in an environment with a temperature of 23°C ±3°C 73.4°F ±5.4°F. ^2 Max. expansion: 180 ch (with 45 units connected, using NR-X100W), 20 ch (with 5 units connected, using NR-500) ^3 At a frequency of 40 kHz or less ^4 Limited by the NR-X100W buffer memory when using the NR-X100W.

Model		NR-FV04 ^*1
Type		Pulse measurement unit
Input method		Insulated single-end input, channels insulated from each other, input channels insulated from other units (PC)
Number of channels		4 ch ^*2
Measurement cycle		Maximum sampling cycle: 1 μs (1 MHz) to 60 s
A/D converting system		Successive approximation, simultaneous sampling of all channels
A/D resolution		14 bit
Input frequency band		250 kHz (−3 dB or more)
Low pass filter		PASS, 1.5 kHz, 15 kHz, 50 kHz
Pulse input	Input type	Pulse frequency, pulse count (Single-phase input)
	Maximum input voltage	±700 V ^*3
	Threshold voltage	+100 V, +50 V, +20 V, +10 V, +5 V, +2.5 V, +1 V, +500 mV, +250 mV, +100 mV, +50 mV, 0 V
	Minimum pulse duration	2 μs or more for both ON and OFF
	Hysteresis	AUTO, 100 mV, 500 mV, 5 V
	Pulse divisions	1 to 64 (Can be set to units of 1 division)
	Input coupling	DC rising edge, DC falling edge, AC rising edge, AC falling edge
	Digital filter	Pulse frequency: Averaging rate of 1 to 32768 (automatically selected), Pulse count: None
	Predictive functions	Predictive calculation, Stop prediction (OFF, ×1.5, ×3, ×5, ×8, ×16)
	Sensor power output	Dedicated connectors for OP-88003 (AUX POWER) × 2 when using OP-88003; +12 V, 50 mA or +5 V, 50 mA NPN open-collector output connectable, sensor power supply not insulated from system bus
Voltage input	Input type	±100 V, ±50 V, ±20 V, ±10 V, ±5 V, ±2 V
	Maximum input voltage	±700 V ^*3
	Digital filter	Averaging rate: 1 to 128 (automatically selected)
	Input coupling	DC, AC
	Common mode noise reduction ratio	80 dB or more (at up to 60 Hz DC)
	Residual noise level	0.02% of F.S., LPF: 1.5 kHz (200 μs/S, digital filter: ON); 0.05% of F.S., LPF: PASS
Measurement range	Pulse frequency	Measurable range: 0.05 to 16000.00 Hz, Display resolution: 0.01 to 1.00 Hz (selected automatically according to frequency)
	Pulse count	Measurable range: 0 to 65,000 counts/sampling cycle, Display resolution: 1 count
	±100 V	Measurable range: −110.000 to +110.000 V, Display resolution: 5 mV
	±50 V	Measurable range: −55.000 to +55.000 V, Display resolution: 2 mV
	±20 V	Measurable range: −22.000 to +22.000 V, Display resolution: 1 mV
	±10 V	Measurable range: −11.0000 to +11.0000 V, Display resolution: 0.5 mV
	±5 V	Measurable range: −5.5000 to +5.5000 V, Display resolution: 0.2 mV
	±2 V	Measurable range: −2.2000 to +2.2000 V, Display resolution: 0.1 mV
Measurement accuracy	Pulse frequency	±0.07% of rdg, ±0.01 Hz (20 Hz to 15 kHz, 20 ms/S, with digital filter ON)
	Voltage input	±0.1% of F.S., LPF: 500 Hz, with digital filter ON
Withstand voltage	Input to system bus/earth	2200 VAC (50/60 Hz) for 1 minute
Connector format		Insulated BNC connector
Input impedance		1 MΩ ±1%, approx. 30 pF
Buffer memory		16M data^*4
Warm up time		30 minutes or more
Maximum allowable voltage to ground		[When using OP-89263 1:1 voltage-resistant probe] Measurement terminal, GND terminal: 300 Vrms (CAT II); [When using OP-89264 1:1 voltage-resistant probe] Measurement terminal, GND terminal: 300 Vrms (CAT II); [When using OP-88998 10:1 voltage-resistant probe] Measurement terminal: 700 Vrms (CAT II), GND terminal: 300 Vrms (CAT II); [Direct input] Measurement terminal, GND terminal: 42.4 Vpeak and 30 Vrms, or 60 VDC ^*3
Rating	Power consumption	4 W or less (including OP-88003 sensor power supply)
Environmental resistance	Insulation resistance	500 VDC, 10 MΩ or more
	Ambient temperature	0 to +40°C 32°F to 104°F
	Relative humidity	10 to 85% RH (no condensation)
Weight		Approx. 270 g 9.53 oz
^1 The above specifications are the values when zero point adjustment is performed after the warm-up period in an environment with a temperature of 23°C ±3°C 73.4°F ±5.4°F. ^2 Max. expansion: 180 ch (with 45 units connected, using NR-X100W), 20 ch (with 5 units connected, using NR-500) ^3 At a frequency of 40 kHz or less ^4 Limited by the NR-X100W buffer memory when using the NR-X100W.
