The Mitsubishi MR-J2S-100A-S004 is a general-purpose AC servo amplifier from the MELSERVO J2-Super series, designed for precise motor control in industrial automation and control systems. This 1 kW servo drive employs sine-wave PWM control and current control methodology to deliver accurate position, speed, and torque control capabilities. The amplifier converts command signals from controllers into precise voltage and current outputs required to drive servo motors with high accuracy. It supports multiple control modes including position control, speed control, and torque control, offering versatility across diverse industrial applications. The unit features a built-in dynamic brake and comprehensive protection functions including overcurrent shut-off, regenerative overvoltage protection, overload protection, encoder error detection, and undervoltage/instantaneous power failure protection. The MR-J2S-100A-S004 includes RS-232C/RS-422 PC interface capability, a 5-digit LED display, and multiple digital and analog I/O options for flexible system integration in manufacturing, packaging, material handling, and precision positioning applications.
Item Details
- Brand Name: Mitsubishi
- Manufacturer: Mitsubishi Electric Corporation
- Item Type Name: AC Servo Amplifier
- Product Family / Series: MELSERVO J2-Super Series
- Model Number: MR-J2S-100A-S004
- Base Model: MR-J2S-100A
- Interface Type: Universal Interface
Product Specifications
- rated_output_power: 1 kW
- supply_voltage: 3-phase 200-230 VAC or 1-phase 230 VAC
- frequency: 50/60 Hz
- permissible_voltage_fluctuation: 170-253 VAC
- permissible_frequency_fluctuation: ±5%
- output_voltage: 170 V
- output_frequency_range: 0-360 Hz
- control_system: Sine-wave PWM control, current control method
- dynamic_brake: Built-in
- control_modes: Position control, speed control, torque control
- max_input_pulse_frequency: 500 kpps (differential receiver), 200 kpps (open collector)
- command_pulse_multiplying_factor: Electronic gear A: 1-65535, 131072; B: 1-65535, 1/50
- speed_command_input: 0-10 VDC
- torque_command_input: 0-8 VDC
- input_impedance: 10-12 kΩ
- digital_inputs: 24 VDC sink/source (EMG, LSP, LSN, SON, RES, PC/ST1/RS2, TL/ST2/RS1, SP2)
- communication_interface: RS-232C/RS-422
- display: 5-digit LED display
- parameter_adjustment: 4 keys/buttons
- inrush_current_main_circuit: 120 A
- inrush_current_control_circuit: 100-130 A
Additional Details
- Lifecycle Status: Discontinued
- Protection Functions: Overcurrent shut-off, regenerative overvoltage shut-off, overload shut-off (electronic thermal), servo motor overheat protection, encoder error protection, regenerative error protection, undervoltage/sudden power outage protection, overspeed protection, excessive error protection
- Encoder Compatibility: Incremental or absolute encoders
- Compatible Servo Motors: HC-SFS81, HC-SFS102, HC-SFS103, HC-LFS102 series
- Mounting Clearance Requirements: 40 mm above, 10 mm each side
- Ambient Operating Temperature: 0 to +55 °C
- Storage Temperature: -20 to +65 °C
- Relative Humidity: ≤90% (non-condensing)
- Cooling Method: Natural convection (no fan for 100A model)
Measurements
- Weight: 1.7 kg
