| Characteristic | Value(s) |
|---|---|
| Test function | Remote test Remote test (via communication) Local |
| Signal contacts composition | 1 C/O alarm fail-safe 1 NO pre-alarm fail-safe |
| Type of measurement | Earth fault current internal measurement, range: 20...200 %, accuracy: +/- 20 % |
| Refresh time | 0.5 s |
| Communication service | Modbus slave |
| Tamperproof of settings | Protected by access code |
| Connections - terminals | Alarm circuit: terminal block cable(s) 0.2â¦2.5 mm² flexible AWG 22...AWG 12 Alarm circuit: terminal block cable(s) 0.2â¦2.5 mm² rigid AWG 22...AWG 12 Relay test and fault reset: terminal block cable(s) 0.2â¦2.5 mm² flexible AWG 22...AWG 12 Relay test and fault reset: terminal block cable(s) 0.2â¦2.5 mm² rigid AWG 22...AWG 12 Sensor: terminal block cable(s) 0.2â¦2.5 mm² flexible AWG 22...AWG 12 Sensor: terminal block cable(s) 0.2â¦2.5 mm² rigid AWG 22...AWG 12 Voltage presence: terminal block cable(s) 0.2â¦2.5 mm² flexible AWG 22...AWG 12 Voltage presence: terminal block cable(s) 0.2â¦2.5 mm² rigid AWG 22...AWG 12 Power supply: terminal block cable(s) 0.2â¦2.5 mm² flexible AWG 22...AWG 12 Power supply: terminal block cable(s) 0.2â¦2.5 mm² rigid AWG 22...AWG 12 Pre alarm: terminal block cable(s) 0.2â¦2.5 mm² flexible AWG 22...AWG 12 Pre alarm: terminal block cable(s) 0.2â¦2.5 mm² rigid AWG 22...AWG 12 |
| Wire stripping length | Alarm circuit: 6 mm Relay test and fault reset: 6 mm Sensor: 6 mm Voltage presence: 6 mm Power supply: 6 mm Pre alarm: 6 mm |
| Tightening torque | Alarm circuit: 0.5 N.m Relay test and fault reset: 0.5 N.m Sensor: 0.5 N.m Voltage presence: 0.5 N.m Power supply: 0.5 N.m Pre alarm: 0.5 N.m |
| Standards | EN/IEC 60947-2 Annex M EN/IEC 60755 |
| Width | 72 mm |
| Height | 72 mm |
| Depth | 117 mm |
| Cut-out dimensions | 68 x 68 mm |
| Product weight | 0.3 kg |
| IP degree of protection | IP40 front face: conforming to IEC 60529 IP30 other parts: conforming to IEC 60529 IP20 connection: conforming to IEC 60529 |
| IK degree of protection | IK07 conforming to EN 50102 |
| Mechanical robustness | Vibrations 13.2...100 Hz: 0.7 g Vibrations 2...13.2 Hz: +/- 1 mm |
