The Keyence LJ-V7000 Series is a high-speed inline profile measurement system designed for non-contact 2D and 3D laser scanning applications in industrial automation. Operating at 64,000 profiles per second and 12,800,000 points per second, it provides precision inspection of fast-moving parts on production lines. The system utilizes a blue laser at 405 nm wavelength combined with a proprietary HSE3-CMOS sensor to achieve an industry-leading wide dynamic range, enabling accurate measurement across varying surface types including black rubber, transparent glass, and highly reflective metals. The modular system comprises a controller and interchangeable sensor heads optimized for different accuracy and range requirements. Communication interfaces include Ethernet, USB, and RS-232C, with onboard memory capable of storing up to 60,000,000 data points. Applications include height measurement, weld inspection, 3D shape analysis, and robotic guidance in automotive, electronics, and manufacturing industries.
Item Details
- Brand Name: Keyence
- Manufacturer: Keyence Corporation
- Item Type Name: High-Speed 2D/3D Laser Profiler System
- Product Family / Series: LJ-V7000 Series
Product Specifications
- sampling_rate: 64,000 profiles/sec
- measurement_speed: 12,800,000 points/sec
- laser_wavelength: 405 nm (blue laser)
- sensor_technology: HSE3-CMOS
- memory_capacity: 60,000,000 data points or 250,000 profiles
- communication_interfaces: Ethernet, USB, RS-232C
- output_types: Analog voltage, digital I/O, NPN/PNP
- exposure_time_min: 15.6 μs at 64 kHz
Additional Details
- Controller Models: LJ-V7001 (NPN), LJ-V7001P (PNP)
- Sensor Head Options: LJ-V7020/K (ultra-high accuracy), LJ-V7060/K (high accuracy), LJ-V7080, LJ-V7200, LJ-V7300
- Environmental Rating: IP67 (sensor heads)
- Software Included: LJ-Navigator2, LJ-Observer, Communication Library
