The Foxboro IGP10-T22D1F-L1 is an intelligent two-wire gauge pressure transmitter from the I/A Series product family. It provides precise and reliable measurement of gauge pressure in industrial process applications. The transmitter features a 316L stainless steel process connection and sensor with silicone fill fluid, designed for demanding environments. It outputs a 4-20 mA signal with superimposed HART digital protocol, enabling remote configuration and monitoring. The device offers superior performance with accuracy of 0.2% of span including hysteresis, linearity, and repeatability. Long-term stability is exceptional, with drift less than 0.05% of upper range limit per year over a five-year period. The robust construction includes dual-compartment aluminum housing with epoxy finish for moisture and dust protection, and 1/2 NPT conduit connections on both sides.
Item Details
- Brand Name: Foxboro
- Manufacturer: Schneider Electric
- Item Type Name: Intelligent Gauge Pressure Transmitter
- Product Family / Series: I/A Series
- Electronics Version: Digital HART/4-20 mA
- Structure Code: 316L ss process connection, 316L ss sensor
- Sensor Fill Fluid: Silicone
- Process Connection: 1/2 NPT external thread, 1/4 NPT internal thread
Product Specifications
- output_signal: 4-20 mA DC with HART digital
- pressure_range: 0.7 to 21 bar (10 to 300 psi, 0.07 to 2.1 MPa)
- accuracy: ±0.2% of span
- long_term_stability: ±0.05% of URL per year over 5 years
- sensor_material: 316L stainless steel
- process_cover_material: 316L stainless steel
- conduit_connection: 1/2 NPT both sides
- housing_material: Aluminum alloy with epoxy finish
- calibration_frequency: 5 years
- process_temperature_limit: 121°C (250°F) with silicone fill fluid
Additional Details
- Lifecycle Status: Discontinued by manufacturer
- Mounting: Any orientation
- Protection: Conformally coated electronics for moisture and dust
Measurements
- Weight: 1.54 kg (3.40 lbs)
