The FX3S-14MR/ES is an entry-level compact programmable logic controller (PLC) CPU main unit from Mitsubishi Electric's MELSEC-F series. This all-in-one unit integrates power supply, CPU, and I/O in a single module, featuring 8 digital inputs (24V DC, sink/source) and 6 relay outputs, providing a total of 14 I/O points. The unit operates on 100-240V AC power supply and includes 16K steps of EEPROM program memory. Built-in features include high-speed counters and positioning outputs. The FX3S supports multiple programming languages including ladder diagram, function block diagram, structured text, and sequential function chart. With a compact IP10 protection class design, fast instruction cycle times (210ns for contact instructions), and integrated RS-422 and USB communication ports, this PLC is ideal for small-scale automation applications in manufacturing, packaging, and material handling systems.
Item Details
- Brand Name: Mitsubishi
- Manufacturer: Mitsubishi Electric
- Item Type Name: Compact PLC CPU Main Unit
- Product Family / Series: MELSEC-F
- Series: FX3S
Product Specifications
- power_supply: 100-240 V AC
- integrated_digital_inputs: 8
- input_voltage: 24 V DC
- input_type: Sink/Source
- integrated_digital_outputs: 6
- output_type: Relay
- total_io_points: 14
- local_io_points: 30
- program_memory: 16K steps
- program_memory_type: EEPROM
- auxiliary_relays: 1536 points
- timers: 138 points
- counters: 67 points
- data_registers: 3000 points
- file_registers: 2000 points
- cycle_time_ld: 210 ns
- cycle_time_mov: 500 ns
- power_consumption: 19 W
- protection_class: IP10
- operating_temperature_min: 0 °C
- expandable: No
- usb_ports: 1
- rs422_ports: 1
Additional Details
- Country of Origin*: Japan
- Certifications / Approvals: CE, UL, cUL, EAC, UKCA, ABS, BV, DNV GL, LR, NK
- Rohs Compliance: Compliant
- Weee Category: B2B
- Commodity Code: 85371091
- Programming Languages: Ladder diagram (LD), Function Block Diagram (FBD), Structured Text (ST), Sequential Function Chart (SFC)
