| Manufacturer | Lenze |
|---|---|
| Series | Series 9300 |
| Part Number | EVS9327-CPV003 |
| Controller Type | Servo Position Controller |
| Rated Current (400V with Mains Choke) | 27.0 A |
| Rated Current (400V without Mains Choke) | 43.5 A |
| Typical Motor Power (4-pole) | 15.0 kW (20.0 hp) |
| Mounting Position | Vertical |
| Maximum Output Current (480V) | 48.0 A |
| Power Loss | 430 W |
| Rated Power (400V) | 15 kW |
| Rated Power (480V) | 18.5 kW |
| Protection Type | IP20 |
| AC Mains Voltage Range | 320 V to 528 V |
| AC Mains Frequency Range | 45 Hz to 65 Hz |
| DC Mains Voltage Range | 450 V to 740 V |
| Storage Temperature Range | -25 ... +55 °C |
| Vibration Resistance Standards | EN 50178, EN 61800−5−1, Germanischer Lloyd |
