The Beckhoff EL7211-9014 is a single-channel EtherCAT servo terminal featuring integrated One Cable Technology (OCT) for compact, high-performance motion control. Designed for permanent magnet-excited three-phase synchronous servomotors from the AM8100 series, it delivers continuous output current up to 4.5 A RMS with peak capability of 9.0 A for 1 second. OCT combines motor power and absolute feedback signals in a single cable, significantly reducing wiring complexity. The terminal automatically reads the electronic nameplate of AM81xx motors for instant parameter configuration. Advanced field-oriented current control and PI speed regulation enable fast, highly dynamic positioning tasks. Comprehensive monitoring includes overvoltage, undervoltage, overcurrent, terminal temperature, and motor load calculation via I²T modeling. The unit integrates Safe Torque Off (STO) functionality compliant with Category 3, Performance Level d for enhanced operational safety. Communication via high-speed EtherCAT with CANopen over EtherCAT (CoE) application layer ensures seamless integration with TwinCAT PC-based control systems.
Item Details
- Brand Name: Beckhoff
- Manufacturer: Beckhoff Automation
- Item Type Name: EtherCAT Servo Terminal
- Product Family / Series: EL7xxx Compact Drive Technology
- Series: EL72x1-901x Servo Motor Terminals
- Motion Profile: MDP742
- Compatible Motors: AM8100 series (AM81xx) servomotors
Product Specifications
- number_of_channels: 1
- motor_type: Permanent magnet-excited three-phase synchronous motor
- continuous_output_current: 4.5 A RMS
- peak_output_current: 9.0 A RMS (1 second)
- supply_voltage_electronics: 24 V DC
- supply_voltage_power: 8 to 48 V DC
- nominal_motor_voltage: 48 V DC
- current_controller_frequency: 32 kHz
- pwm_clock_frequency: 16 kHz
- rotating_field_frequency: 0 to 599 Hz
- communication_protocol: EtherCAT
- application_layer: CANopen over EtherCAT (CoE)
- fieldbus_current_consumption: 120 mA (E-bus)
- power_contact_current_consumption: 100 mA + holding current
- status_leds: 16 diagnostic LEDs
- distributed_clocks: Yes
- safe_torque_off_sto: Yes (Cat. 3, PL d)
Additional Details
- Country of Origin*: Germany
- Protection Rating: IP20
- Approvals: CE, UL
- Emc Immunity: EN 61000-6-2
- Emc Emission: EN 61000-6-4
- Vibration Resistance: EN 60068-2-6
- Shock Resistance: EN 60068-2-27
- Mounting: 35 mm DIN rail (EN 60715)
- Housing Material: Polycarbonate
- Housing Type: HD (High Density) with signal LEDs
- Connection System: Double slot and key connection
*Country of origin may vary.
Measurements
- Weight: 95 g
- Dimensions: 24 mm x 100 mm x 68 mm (W x H x D)
- Operating Temperature: 0 to +55 °C
- Storage Temperature: -25 to +85 °C
- Relative Humidity: 95% (non-condensing)
