The Beckhoff EL7037 is a compact single-channel EtherCAT Terminal designed for direct connection and control of 2-phase stepper motors in the low power range up to 1.5 A. This motion interface integrates a stepper motor output stage with two digital inputs for limit switches and incremental encoder input capability in a single DIN rail-mountable housing. The terminal features 64-fold micro-stepping for quiet and precise motor operation, along with PWM output stages that support both unipolar and bipolar stepper motors. It can be easily parameterized to match specific motor and application requirements, and supports vector control for AS10xx series stepper motors, offering improved dynamics and reduced power consumption. The output current can be increased to 3 A when used with the optional ZB8610 fan cartridge. Ideal for compact drive solutions when paired with Beckhoff AS2000 stepper motors featuring integrated encoders, the EL7037 is commissioned using TwinCAT 3 Drive Manager 2.
Item Details
- Brand Name: Beckhoff
- Manufacturer: Beckhoff Automation
- Item Type Name: EtherCAT Stepper Motor Terminal
- Product Family / Series: EL70x7 Stepper Motor Terminals
Product Specifications
- supply_voltage: 24 V DC (-15% / +20%)
- output_current_max: 1.5 A
- output_current_with_ZB8610: 3.0 A
- number_of_channels: 1
- load_type: 2-phase stepper motor (uni-/bipolar)
- step_pattern: 64-fold micro-stepping
- step_frequency_max: 16,000 full steps/s
- current_controller_frequency: 30 kHz
- resolution: 5000 positions
- encoder_input_signal: 5-24 V DC, 5 mA, single-ended
- encoder_compatibility: 1,024 inc/rev (AS2000 motors)
- number_of_inputs: 2 (limit switches), 1 (encoder)
- number_of_outputs: 1 stepper motor, 1 motor brake (0.5 A)
- electrical_isolation: 500 V
- operating_temperature: 0 to +55 °C
- storage_temperature: -25 to +85 °C
- protocol: EtherCAT
Additional Details
- Certifications / Approvals: CE, UL
- Emc Compliance: EN 61000-6-2 / EN 61000-6-4
- Vibration Shock Resistance: EN 60068-2-6 / EN 60068-2-27
- Protection Rating: IP20
- Housing Material: Polycarbonate
- Design Form: HD (High Density) housing with signal LEDs
- Mounting: 35 mm DIN rail, EN 60715
- Commissioning Tool: TwinCAT 3 Drive Manager 2
- Compatible Motors: AS10xx, AS2000 series
Measurements
- Weight: 50 g
- Dimensions: 12 mm x 100 mm x 68 mm (W x H x D)
