The Delta ECMA-J11330R4 is a high-performance three-phase AC servo motor designed for precision motion control in industrial automation applications. Part of Delta's ASDA-A2 series servo system, this motor delivers 3 kW of rated power at 3000 RPM with a rated torque of 9.55 Nm. The motor features a low to medium inertia design with a 130 mm frame size and is equipped with a 20-bit incremental encoder providing 1,280,000 pulses per revolution for exceptional positioning accuracy. Designed for 400 VAC supply voltage, the motor incorporates an oil seal for enhanced reliability and includes keyway with screw hole for secure shaft coupling. With IP65 protection rating and maximum speed capability of 4500 RPM, the ECMA-J11330R4 is suitable for demanding applications including CNC machinery, robotic arms, packaging equipment, precision machining centers, and automated manufacturing systems requiring high-precision motion control and smooth operation.
Item Details
- Brand Name: Delta
- Manufacturer: Delta Electronics, Inc.
- Item Type Name: AC Servo Motor
- Product Family / Series: ECMA-J Series / ASDA-A2 Series
- Part Number: ECMA-J11330R4
- Motor Type: Three-phase permanent magnet AC servo motor
Product Specifications
- rated_power: 3 kW
- rated_torque: 9.55 Nm
- rated_speed: 3000 RPM
- maximum_torque: 28.65 Nm
- maximum_speed: 4500 RPM
- supply_voltage: 400 VAC
- encoder_type: 20-bit incremental
- encoder_resolution: 1280000 pulses/rev
- frame_size: 130 mm
- shaft_diameter: 24 mm
- inertia_class: Low to medium inertia
- protection_rating: IP65
- frequency_response: Up to 1 kHz
- brake: Without brake
- shaft_configuration: Keyway with screw hole
- oil_seal: With oil seal
Additional Details
- Country of Origin*: Taiwan
- Certifications / Approvals: CE compliant
- Applications: CNC machinery, robotic arms, packaging equipment, machining centers, textile machinery, injection molding, printing equipment, automated production lines
- Compatible Drives: ASDA-A2 400V Series Servo Drives
- Communication Protocols: CANopen, DMCNET, EtherCAT (drive dependent)
*Country of origin may vary.
Measurements
- Flange Dimension: 130 mm x 130 mm
