The Delta DVP20SX211S is a compact 20-point slim-type programmable logic controller from the DVP-SX2 Series, featuring 8 digital inputs, 6 digital outputs, 4 analog inputs, and 2 analog outputs. This second-generation analog I/O PLC operates on 24 VDC power supply and offers 16k steps of program memory with 10k words of data register capacity. The controller supports transistor output (PNP) and includes advanced features such as two high-speed pulse outputs at 100 kHz, 2-axis interpolation instructions, and connectivity with Delta slim series extension modules for up to 480 maximum I/O points. The DVP20SX211S utilizes battery-free flash memory for program and data storage, supports Modbus ASCII/RTU protocols and PLC Link function, and is designed for chassis or DIN rail mounting in industrial automation applications including PID temperature control, humidity monitoring, and motor drive systems.
Item Details
- Brand Name: Delta
- Manufacturer: Delta Electronics Industrial Automation
- Item Type Name: Programmable Logic Controller (PLC)
- Product Family / Series: DVP-SX2 Series
- Model Number: DVP20SX211S
- Output Type: Transistor (PNP)
- Mounting Type: Chassis Mount, DIN Rail
Product Specifications
- power_supply_voltage: 24 VDC (-15% to +20%)
- voltage_range: 20.4 to 28.8 VDC
- power_consumption: 4.7 W
- program_memory: 16k steps
- data_register: 10k words
- digital_inputs: 8
- digital_outputs: 6
- analog_inputs: 4 (12-bit resolution)
- analog_outputs: 2 (12-bit resolution)
- max_io_expansion: 480 points
- high_speed_pulse_outputs: 2 groups at 100 kHz
- analog_input_voltage_range: ±10 V
- analog_input_current_range: ±20 mA, 4-20 mA
- analog_output_voltage_range: ±10 V
- analog_output_current_range: 0-20 mA, 4-20 mA
- communication_protocol: Modbus ASCII/RTU, PLC Link
- auxiliary_power_supply: 5-30 VDC (UP, ZP terminals)
- auxiliary_power_consumption: 5 mA/point
Additional Details
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -25°C to 70°C
- Operating Humidity: 50% to 95% non-condensing
- Storage Humidity: 5% to 95% non-condensing
- Insulation Resistance: >5 MΩ at 500 VDC
- Esd Protection: 8 kV air discharge
- International Standards: IEC61131-2, IEC 68-2-6, IEC 68-2-27
- Pollution Degree: 2
- Memory Type: Flash memory (battery-free design)
Measurements
- Weight: 243 g
