The Red Lion CUB5B00B is a compact 8-digit dual counter and rate indicator with backlight LCD display, providing versatile counting and rate measurement in a 1/16 DIN panel-mount package. This miniature meter offers complete user programmability and can function as a single counter, dual counter, or counter with rate indication capability. The display features 11.7 mm high digits with user-selectable green or red backlighting and variable intensity control. It accepts pulse inputs up to 20 kHz and supports eight different count modes including bi-directional counting, quadrature sensing, up/down control, anti-coincidence counting, and batch counting. Input A processes signals for count and rate displays, while Input B handles count signals or direction control. The unit features separate scaling factors and decimal point placement for different engineering units, programmable update times, and optional setpoint control and serial communication capabilities through plug-in modules.
Item Details
- Brand Name: Red Lion
- Manufacturer: Red Lion Controls
- Item Type Name: Miniature Electronic Dual Counter and Rate Indicator
- Product Family / Series: CUB5 Series
Product Specifications
- display_type: 8-digit LCD with red/green backlight
- digit_height: 11.7 mm
- supply_voltage: 9 to 28 V DC
- operating_temperature_range: -35 to 75 °C
- count_modes: 8 programmable modes
- maximum_count_speed: 20 kHz
- panel_cutout_height: 33.02 mm
- panel_cutout_width: 68.07 mm
- enclosure_rating: NEMA 4X / IP65
- input_polarity_protection: Yes
- short_circuit_protection: Yes
Additional Details
- Mounting Type: Panel mount
- Communication Options: RS232 / RS485 (optional plug-in cards)
- Setpoint Options: Single relay or dual sinking (optional plug-in cards)
- Programming Interface: Front panel or Crimson software via USB
- Power Options: DC standard, AC available with optional MLPS module (85-250 V AC)
Measurements
- Weight: 0.18 lbs
- Dimensions: 39.1 mm H x 74.9 mm W x 43.4 mm D
