The Red Lion CUB4V000 is a compact DC digital voltmeter designed for industrial voltage measurement applications. It features a 3.5-digit LCD display with positive image reflective technology, displaying black digits on a reflective background for easy readability without backlighting. The unit measures 75 mm × 39 mm and fits standard DIN panel cutouts. It offers four selectable DC voltage ranges from 0-199.9 mV to 0-199.9 V, with DIP switch selectable decimal points and built-in scaling via potentiometer. The lightweight, high-impact plastic case with clear viewing window provides NEMA 4X/IP65 rated protection for use in wash-down and dusty industrial environments. Operating from 9-28 V DC power supply, the meter includes automatic offset correction and auto-zeroing circuitry for accurate measurements.
Item Details
- Brand Name: Red Lion Controls
- Manufacturer: Red Lion Controls
- Item Type Name: DC Digital Voltmeter
- Product Family / Series: CUB4 Series
- Part Number: CUB4V000
- Display Type: LCD Positive Image Reflective
- Display Digits: 3.5-Digit
- Meter Function: DC Voltage Measurement
Product Specifications
- voltage_ranges: 0-199.9 mV / 0-1.999 V / 0-19.99 V / 0-199.9 V DC
- accuracy: ±0.1% ±1 digit
- digit_height: 15.2 mm
- supply_voltage: 9-28 V DC
- response_time: 1.5 sec
- analog_inputs: 1
- operating_temperature: 0 to 60 °C
Additional Details
- Country of Origin*: US
- Certifications / Approvals: CE, EN 61326-1, EN 61010-1, IEC 60068-2-6, RoHS Compliant, UL Hazardous Locations
- Protection Rating: NEMA 4X / IP65
- Connection Type: Screw clamp terminals
- Features: DIP switch selectable decimal point, built-in scaling potentiometer, automatic offset correction, auto-zeroing circuit
*Country of origin may vary.
Measurements
- Panel Dimensions: 75 mm × 39 mm
- Panel Cutout: 68.07 mm × 33.02 mm
