The Yaskawa CIPR-GA50U4009ABAA-AAAASA is an industrial AC microdrive from the GA500 series, engineered for precise motor control in demanding industrial automation applications. This compact drive delivers 5 HP normal duty or 4 HP heavy duty performance from a 400V three-phase input, providing versatile speed and torque control for pumps, fans, conveyors, and compressor systems. The drive features current vector control with support for induction motors, permanent magnet motors, and synchronous reluctance motors. Key capabilities include conformal coating for harsh environments, embedded Modbus communication, an integrated 24 VDC power supply, and SIL3/PLe safety ratings. The intuitive keypad interface, no-power programming feature, and maintenance monitors simplify installation and operation. With IP20 enclosure protection and a compact footprint up to 30% smaller than competitive models, the GA500 maximizes performance while minimizing panel space requirements.
Item Details
- Brand Name: Yaskawa
- Manufacturer: Yaskawa Electric Corporation
- Item Type Name: AC Variable Frequency Drive
- Product Family / Series: GA500
- Model Number: GA50U4009ABA
- Full Part Number: CIPR-GA50U4009ABAA-AAAASA
- Series: GA500 Industrial AC Microdrive
Product Specifications
- input_voltage: 380-480 V AC
- input_phase: 3-phase
- power_rating_normal_duty: 5 HP (3.7 kW)
- power_rating_heavy_duty: 4 HP (3.0 kW)
- output_current_normal_duty: 8.9 A
- output_current_heavy_duty: 7.3 A
- voltage_class: 400 V Class
- max_frequency: 590 Hz
- control_method: Current Vector Control, Open Loop
- motor_compatibility: Induction Motor (IM), Permanent Magnet Motor (PM), Synchronous Reluctance Motor
- overload_capacity_heavy_duty: 150% for 1 minute
- communication_protocol: Embedded Modbus
- safety_rating: SIL3 (IEC 62061), PLe (ISO 13849-1)
- environmental_coating: Conformal coated (IEC 60721-3-3: 3C2, 3S2)
- enclosure_rating: IP20
- embedded_power_supply: 24 V DC
- keypad: Intuitive keypad included
Additional Details
- Certifications / Approvals: SIL3 (IEC 62061), PLe (ISO 13849-1), IEC 60721-3-3: 3C2, 3S2
- Mounting Options: Panel, Side-by-side, External heatsink, DIN rail
- Special Features: No power programming, Tool-free cooling fan replacement, Maintenance monitors
- Ambient Temperature Rating: -10 to +50 °C (standard)
- Cooling Method: Forced air cooling with fan
Measurements
- Weight: 0.91 kg (2 lb)
- Width: 108 mm (4.25 in)
- Height: 128 mm (5.04 in)
- Depth: 154 mm (6.06 in)
