The Yaskawa CIMR-J7AA41P5 is a compact general-purpose variable frequency drive from the VS mini J7 series, designed for precise motor speed control in industrial applications. This 400V class inverter provides 1.5 kW motor control capability with three-phase input and output, utilizing sine wave PWM voltage-to-frequency control methodology. The drive features a wide output frequency range from 0.1 to 400 Hz, making it suitable for pumps, fans, conveyors, and general machinery applications. It includes a digital operator with LED display for monitoring frequency reference, output frequency, and current. The compact design allows easy installation in space-constrained environments while maintaining reliable performance. The J7 series is known for its simplicity and ease of use, comparable to a contactor, with straightforward programming and 2-wire control as the factory default setting.
Item Details
- Brand Name: Yaskawa
- Manufacturer: Yaskawa Electric Corporation
- Item Type Name: Variable Frequency Drive (AC Inverter)
- Product Family / Series: VS mini J7
- Series: J7 / GPD-305
- Model Code: CIMR-J7AA41P5
Product Specifications
- motor_output_power: 1.5 kW
- input_voltage: 380-460 V AC
- input_phases: 3-phase
- input_frequency: 50/60 Hz
- output_voltage: 0-460 V AC (proportional to input)
- output_phases: 3-phase
- output_frequency_range: 0.1-400 Hz
- rated_output_current: 4.8 A
- input_current: 7.0 A
- control_method: Sine wave PWM (V/f control)
- overload_capacity: 150% rated current for 1 minute
- frequency_accuracy_digital: ±0.01% (-10 to +50°C)
- frequency_accuracy_analog: ±0.5% (25±10°C)
- acceleration_deceleration_time: 0.1-999 seconds (independently programmable)
- enclosure_type: Open chassis
- cooling_method: Self-cooling
- protection_rating: IP20
Additional Details
- Lifecycle Status: Discontinued by manufacturer
- Control Configuration: 2-wire control (factory default)
- Digital Inputs: 4 multifunction digital inputs
- Display Type: 3-character, 7-segment LED display
- Communication: Digital Operator (JVOP-140) compatible
- Terminal Type: Main circuit: screw terminals, Control circuit: plug-in screw terminal
- Ambient Temperature Operating: -10 to +50°C
- Storage Temperature: -20 to +60°C
- Humidity: 95% RH or less (non-condensing)
- Elevation: 1000 m or less
- Installation Location: Indoor (free from corrosive gases or dust)
Measurements
- Weight: 1.57 kg
