The Yaskawa CIMR-E7U4011 is a Varispeed E7 series AC inverter drive designed exclusively for commercial HVAC applications. This 3-phase drive controls motor speed and torque for variable torque applications such as fans, pumps, and blowers. It features embedded building automation communications protocols including Metasys N2, APOGEE FLN, and Modbus, with optional EtherNet/IP, Modbus TCP/IP, and LonWorks connectivity. The drive is plenum-rated and includes specialized HVAC functions such as anti-windmilling, motor preheat, energy-savings, and PI setpoint control. It provides smooth acceleration and deceleration control while optimizing energy efficiency. The E7 series is known for reduced motor bearing current and extended motor bearing life compared to standard inverters.
Item Details
- Brand Name: Yaskawa
- Manufacturer: Yaskawa Electric
- Item Type Name: Variable Frequency Drive (VFD)
- Product Family / Series: Varispeed E7
- Series: E7U
- Model Number: CIMR-E7U4011
- Enclosure Type: NEMA 1 (IP20)
Product Specifications
- input_voltage: 380-480 V AC
- input_frequency: 50/60 Hz
- input_current: 33 A
- input_phases: 3-phase
- output_voltage: 0-480 V AC
- output_frequency: 0-120 Hz
- output_current: 27 A
- power_rating: 21 kVA
- motor_power_rating_480V: 11 kW (15 HP)
- motor_power_rating_alternate: 20 HP
Additional Details
- Lifecycle Status: Discontinued by manufacturer
- Primary Application: Commercial HVAC - fans, pumps, blowers
- Communication Protocols: Metasys N2, APOGEE FLN, Modbus (embedded); EtherNet/IP, Modbus TCP/IP, LonWorks (optional)
- Special Features: Anti-windmilling, motor preheat, energy-savings, PI setpoint control, plenum-rated
Measurements
- Weight: 5.9 kg (13.0 lbs)
