BT-A700GA Keyence

Specifications

Model			BT-A700GA
Controller	CPU		Qualcomm Octa-core
	OS		Android^TM 13
Main memory	RAM		4 GB
	ROM		32 GB
Display	LCD	Type	5.0" TFT color LCD, IPS type
		Resolution	720 × 1280
		Backlight	High-intensity white LED
	Operation Status LED		3-color LED (red, green, blue, yellow, cyan, magenta, white)
Operations	Hard Keys		10 keys
	Touch Panel		Electrostatic capacitance method (Gorilla Glass)
Scanner	Reading Specification	Reading Light Source	High-intensity white LED
		Pointer Light Source	Visible semiconductor laser (650 nm) Output 700 μW Class 2 laser product (IEC 60825-1) ^*1
		Minimum Resolution	2D code: 0.191 mm .008" Barcode: 0.127 mm 0.005"
			80 to 1550 mm 3.15" to 61.02" (CODE39 narrow bar width: 0.254 mm 0.01") 25 to 4100 mm 0.98" to 161.42" (CODE39 narrow bar width: 0.508 mm 0.02") 100 to 370 mm 3.94" to 14.57" (QR cell size: 0.254 mm 0.01") 0 to 1200 mm 0" to 47.24" (QR cell size: 0.508 mm 0.02")
		Reading Width (Field Range)	151 × 94 mm 5.94" × 3.70" (Reading distance: 300 mm 11.81")
	Supported Code		JAN/EAN/UPC (add-on code support), CODE128, GS1-128, CODE39, NW-7 (Codabar), CODE93, ITF, COOP 2of5, Industrial 2of5, QR code, Micro QR, DataMatrix (ECC-200), PDF417, GS1 DataBar, Composite, Postal
Wireless Communication	Wireless LAN	Wireless Radio	IEEE 802.11a/b/g/n/ac
		Frequency Range	2.4 GHz (b, g, n: 1 to 11ch) 5.2 GHz, 5.3 GHz, 5.6 GHz, 5.8 GHz (a/n/ac) * W52/W53 can only be used indoors.
		Security	Security: WEP (64/128 bit), WPA, WPA2 WPA encryption method: TKIP/AES Authentication: PSK, PEAP, EAP-TLS, EAP-TTLS, EAP-PWD
	Bluetooth^®	Wireless Radio	Bluetooth^® V5.0 + BR/EDR/LE
		Supported Profile	A2DP, AVRCP, BNEP, HID, HSP, IOPT, OPP, PAN, SPP
		Distance	Approx. 10 m 32.8' (line-of-sight)
Expansion Slot	Supported Media		micro SD/SDHC/SDXC UHS-I
Power Source	Main Battery	Type	Dedicated lithium-ion battery pack
		Capacity	6250 mAh
		Continuous Usage Time	Approx. 32 hours ^*2
		Charging time	Approx. 6 hours (room temperature)
	Backup battery	RAM data	Electric double-layer capacitors: 3 minutes ^3 ^4
Others	Audio		Speaker, Microphone
	Vibration		Available
	Camera		5 MP
	Sensor		Accelerometer, Ambient Light, Gyroscope, Digital Compass
Dimensions			88 mm × 134 mm × 235 mm 3.46" × 5.28" × 9.25"
Environmental resistance	Enclosure rating		IP67
	Ambient temperature		−20°C to +50°C -4.0°F to 122°F (No freezing) ^*5
	Relative humidity		20% to 85% RH (No condensation)
	Storage temperature		−20°C to +70°C -4.0°F to 140°F (No freezing)
	Storage relative humidity		20% to 85% RH (No condensation)
	Drop Resistance		Onto concrete from 1.8 m 6'; Up to 20000 impacts from 30 cm 1' (multiple drops to concrete)
Weight			Approx. 487 g (with rechargeable battery pack attached)
^1 The laser classification for FDA (CDRH) is implemented based on IEC60825-1 in accordance with the requirements of Laser Notice. ^2 This is the continuous usage time with the operation confirmation LED and vibration function turned off, with the sound turned on (with low volume), with the backlight turned on (0%), at normal temperature, and when barcode reading is performed and round-trip wireless communication is made once per 20 seconds. This is a test value. The value is not guaranteed. ^3 This indicates the case when the main battery is not attached or the battery has no charge. ^4 This is a typical value, but not a guaranteed value. ^*5 Due to the added load in sub-zero environments, the continuous usage time may be reduced significantly. Be sure to test the device before use in these environments.

Est. delivery between and

$2,378.00

1-year warranty

FREE WORDWIDE SHIPPING

Condition:

Sealed Surplus

SKU: BT-A700GA-Sealed

Sold out

$0.00

Never Used Surplus

SKU: BT-A700GA

2 verified stock

$2,378.00

Used

SKU: BT-A700GA-Used

2 verified stock

$639.92

Variant

Quantity:

Need More?
