The Siemens ECHOMAX XRS-5 (7ML1106-1BA20-0A) is a continuous, non-contact ultrasonic level transducer designed for reliable monitoring of liquids and slurries in wastewater and industrial applications. With a narrow 10-degree beam angle, it is optimized for use in confined spaces such as narrow lift stations, wet wells, flumes, weirs, and filter beds. The transducer features a hermetically sealed CSM rubber face and PVDF copolymer enclosure, providing maximum resistance to methane, saltwater, caustics, and harsh chemicals commonly encountered in wastewater installations. Operating at 44 kHz frequency, the device offers continuous level measurement with a range suitable for municipal and industrial liquid level monitoring applications. It is compatible with a full range of Siemens controllers for applications ranging from basic high/low alarms to advanced SCADA-integrated control systems.
Item Details
- Brand Name: Siemens
- Manufacturer: Siemens
- Item Type Name: Ultrasonic Level Transducer
- Product Family / Series: ECHOMAX XRS-5
- Model: 7ML1106-1BA20-0A
- Part Number Aliases: 7ML11061BA200A
Product Specifications
- measurement_range_min: 0.3 m
- measurement_range_max: 8 m
- beam_angle: 10°
- frequency: 44 kHz
- process_connection: 1 inch NPT
- cable_length: 10 m
- operating_temperature_range: -20°C to +65°C
- measurement_type: Continuous, non-contact
Additional Details
- Country of Origin*: CN
- Face Material: CSM rubber (chlorosulfonated polyethylene)
- Enclosure Material: PVDF copolymer
- Application: Liquids and slurries in lift stations, wet wells, flumes, weirs, and filter beds
*Country of origin may vary.
Measurements
- Weight: 1.58 kg
