The Siemens SIMATIC HMI SMART 700 IE V3 is a compact operator interface panel designed for industrial automation and process visualization applications. It features a 7-inch widescreen TFT touchscreen display with 65536 colors, providing intuitive human-machine interaction for controlling and monitoring automated systems. The panel includes RS422/RS485 serial communication interface, Ethernet connectivity via RJ45 port, and a host USB Type A interface for data transfer and external device connection. It supports real-time clock functionality and multiple industrial protocols including TCP/IP, DHCP, EtherNet/IP, and MODBUS. Configurable using WinCC Flexible SMART software, this HMI panel is suitable for machine control, production line monitoring, and building automation systems requiring reliable operator interface solutions.
Item Details
- Brand Name: Siemens
- Manufacturer: Siemens
- Item Type Name: Human Machine Interface Panel
- Product Family / Series: SIMATIC HMI SMART Panel
- Model: SMART 700 IE V3
- Part Number: 6AV6648-0CC11-3AX0
Product Specifications
- display_size: 7 inch widescreen
- display_type: TFT touchscreen
- display_colors: 65536 colors
- input_voltage_nominal: 24 V DC
- input_voltage_range: 19.2 to 28.8 V DC
- current_consumption_rated: 200 mA
- rs422_interfaces: 1 (combined with RS485)
- ethernet_interfaces: 1 (RJ45)
- usb_interfaces: 1 (host USB Type A)
- real_time_clock: Yes
- tcp_ip_protocol: Yes
- dhcp_protocol: Yes
- ethernet_ip_protocol: Yes
- modbus_protocol: Yes
- profinet_support: No
- profibus_support: No
- configuration_software: WinCC Flexible SMART
Additional Details
- Country of Origin*: Germany
- Lifecycle Status: Discontinued by manufacturer
- Certifications / Approvals: CE certificate
*Country of origin may vary.
Measurements
- Weight: 0.76 kg
