The Siemens SIMATIC HMI KP300 Basic mono PN is a compact operator interface panel designed for basic control and monitoring tasks in industrial automation applications. It features a 3.6-inch monochrome FSTN LCD display with a resolution of 240 x 80 pixels and an LED backlight that can be set to white, green, red, or yellow. The panel includes 10 system keys and 10 configurable function keys for intuitive operation. With a PROFINET interface, the device supports TCP/IP, DHCP, SNTP, LLDP, and DCP protocols for network integration. It is configurable using Siemens TIA Portal with WinCC Basic V11 or STEP 7 Basic V11 software. The device offers 1 MB of user memory and operates on 24 V DC power with a typical consumption of 3 W. Its front panel is rated IP65 for protection against dust and water ingress, making it suitable for harsh industrial environments.
Item Details
- Brand Name: Siemens
- Manufacturer: Siemens
- Item Type Name: HMI Basic Panel
- Product Family / Series: SIMATIC HMI Basic Panels
- Model: KP300 Basic mono PN
- Part Number: 6AV6647-0AH11-3AX1
Product Specifications
- display_size: 3.6 inch
- display_type: FSTN LCD monochrome
- display_resolution: 240 x 80 pixels
- backlight_colors: White, Green, Red, Yellow (LED)
- interface: PROFINET
- ethernet_interfaces: 1
- supported_protocols: TCP/IP, DHCP, SNTP, LLDP, DCP
- user_memory: 1 MB
- processor_type: ARM
- supply_voltage: 24 V DC
- voltage_range: 19.2 to 28.8 V DC
- current_consumption: 0.1 A
- power_consumption: 3 W
- number_of_system_keys: 10
- number_of_function_keys: 10 (configurable)
- configuration_software: WinCC Basic V11 / STEP 7 Basic V11
- front_protection_rating: IP65
Additional Details
- Country of Origin*: DE
- Commodity Code: 85371098
- Rohs Status: Compatible
- Export Control: AL: N / ECCN: EAR99H
- Unspsc: 43201503
*Country of origin may vary.
Measurements
- Weight: 0.38 kg
- Dimensions: 147 x 87.5 mm
- Front Height: 97 mm
