1 year warranty
The Siemens SIMATIC HMI MTP1500 Unified Comfort Panel is a 15.6-inch widescreen human-machine interface designed for industrial automation and machine control. It features a high-resolution TFT display with 16 million colors and intuitive capacitive multi-touch operation for enhanced user interaction. The panel integrates a PROFINET interface for seamless communication with industrial control systems and is configurable using WinCC Unified Comfort V16 engineering software. With its IP65-rated front panel, robust construction, and versatile mounting options, the MTP1500 is suitable for factory automation, real-time process monitoring, machinery operation control, and equipment management in various industrial environments. The device supports modern visualization concepts with significantly improved performance, allowing implementation of larger and more complex applications.
Item Details
- Brand Name: Siemens
- Manufacturer: Siemens
- Item Type Name: HMI Touch Panel
- Product Family / Series: SIMATIC HMI Unified Comfort Panels
- Series: MTP1500 Unified Comfort
- Part Number: 6AV2128-3QB06-0AX1
Product Specifications
- display_size: 15.6 in
- display_type: TFT widescreen
- display_resolution: 1366 x 768 pixels
- colors: 16 million
- touch_technology: Capacitive multi-touch
- interface: PROFINET
- usb_ports: 4 x USB 3.1
- serial_interface: 1 x RS-485 (RS-422 possible)
- number_of_ethernet_ports: 2
- supply_voltage: 24 V DC
- operating_temperature_min: 0 °C
- operating_temperature_max: 50 °C
- ip_rating_front: IP65
- ip_rating_rear: IP20
- configuration_software: WinCC Unified Comfort V16
- maximum_tilt_angle: ±35° from vertical
- backlighting: Adjustable
Additional Details
- Country of Origin*: Germany
- Mounting Type: Panel mounting (vertical or horizontal)
- Includes: Open-source software DVD
*Country of origin may vary.
Measurements
- Weight: 4.3 kg
- Dimensions: 257 x 398 x 73 mm
- Width: 398 mm
- Height: 257 mm
- Depth: 73 mm
