The Siemens SIMATIC HMI MTP700 Unified Comfort Panel is a 7-inch widescreen touch-operated Human Machine Interface designed for industrial automation applications. It features a high-resolution TFT display with 16 million colors and capacitive multi-touch functionality for intuitive operation. The panel provides comprehensive connectivity through dual PROFINET interfaces with integrated switch functionality, one RS-422/RS-485 serial port, four USB 3.1 ports, and dual SD card slots. Configurable using WinCC Unified Comfort V16 or higher, it integrates seamlessly with Siemens automation ecosystems. The front panel meets IP65 protection standards, making it suitable for harsh industrial environments. The device includes a real-time hardware clock with battery backup and supports up to 32 online languages, making it versatile for global deployment in manufacturing, process control, and machine automation applications.
Item Details
- Brand Name: Siemens
- Manufacturer: Siemens
- Item Type Name: Human Machine Interface (HMI) Panel
- Product Family / Series: SIMATIC HMI Unified Comfort Panels
- Model: MTP700 Unified Comfort
- Part Number: 6AV2128-3GB06-0AX1
- Ean Gtin: 4047623411901
Product Specifications
- display_type: TFT
- screen_diagonal: 7 in
- display_resolution: 800 x 480 pixels
- display_width: 152.4 mm
- display_height: 91.4 mm
- number_of_colors: 16777216
- touchscreen_type: Capacitive multi-touch
- profinet_interfaces: 2 (with integrated switch)
- rs422_rs485_interfaces: 1
- usb_ports: 4 x USB 3.1 Gen 1 Type A
- sd_card_slots: 2
- supply_voltage: 24 V DC (19.2-28.8 V DC range)
- onboard_memory: 12 MB
- supported_protocols: TCP/IP, MODBUS, EtherNet/IP, PROFINET
- online_languages_supported: 32
- operating_temperature_range: 0°C to +50°C
- relative_humidity_max: 90% (non-condensing)
- backlighting: Yes, dimmable
- real_time_clock_backup: Approximately 6 weeks
Additional Details
- Country of Origin*: Germany
- Certifications / Approvals: CE, UL, cULus, RCM, EAC, KC
- Protection Class Front: IP65
- Protection Class Rear: IP20
- Configuration Software: WinCC Unified Comfort V16 or higher
- Mounting Orientation: Panel mounting (portrait or landscape)
- Commodity Code: 85371098
- Weee Registration: DE 23691322
*Country of origin may vary.
Measurements
- Weight: 1.72 kg
- Dimensions: 214 mm x 158 mm x 63.6 mm (W x H x D)
