The ABB Vital 1 (part number 2TLA020052R1000) is a configurable safety controller designed for monitoring safety devices such as emergency stops without requiring programming. It utilizes the proprietary DYNlink dynamic single-channel safety signal technology, enabling connection of up to 30 safety sensors in series while achieving Performance Level e (PLe) and Safety Integrity Level 3 (SIL3) according to EN ISO 13849-1 and IEC 62061. The device features two safe relay outputs (2NO contact configuration) and a non-safe information output for reset indication and status feedback to PLCs. It is designed to replace multiple conventional dual-channel safety relays, reducing system complexity and installation time. The controller is suitable for machine safety applications across industrial automation environments.
Item Details
- Brand Name: ABB
- Manufacturer: ABB
- Item Type Name: Safety Controller
- Product Family / Series: Vital Series
- Secondary Brand: Jokab Safety
- Model: Vital 1
- Part Number: 2TLA020052R1000
Product Specifications
- supply_voltage: 24 V DC
- output_current: 1.8 A
- power_consumption: 48 W
- relay_outputs: 2NO (Normally Open)
- output_contact_rating_AC: 2 A at 240 V AC (AC-15)
- output_contact_rating_DC: 1 A at 24 V DC (DC-13)
- input_type: Single channel for dynamic sensors
- dynlink_capacity: Up to 30 sensors in series
- safety_rating: SIL3, PLe, Category 4
- enclosure_rating: IP20/IP40
- operating_temperature: -10 to 55 °C
- rated_insulation_voltage: 250 V
- rated_impulse_voltage: 2.5 kV
- mounting_type: DIN rail
- connection_type: Detachable screw terminal blocks (2 blocks with 7 terminals each)
- reset_mode: Automatic or manual supervised reset
Additional Details
- Rohs Compliant: Yes
- Standards Compliance: EN 60204-1, EN 61496-1, EN 62061, EN ISO 12100, ISO 13849-1, EN 954-1
- Color: Black/Beige
- Gtin Upc Ean: 7350024431810
Measurements
- Weight: 204 g
- Dimensions: 84 mm H x 22.5 mm W x 120 mm D
