1SVR750669R9400 ABB - CM-IVN.S

Ordering

EAN:
4016779852630
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85043121

Dimensions

Product Net Width:
45 mm
Product Net Height:
85.6 mm
Product Net Depth / Length:
104.8 mm
Product Net Weight:
0.179 kg

Technical

Function:
Accessory - Coupling unit for voltage expansion of CM-IWN.1
Up to 690 V AC
Up to 1000 V DC
Accessory - Coupling unit for voltage expansion of CM-IWN.1
Up to 690 V AC
Up to 1000 V DC
Rated Frequency (f):
Measuring Circuit 15 ... 400 Hz
Terminal Type:
Screw Terminals
Rated Impulse Withstand Voltage (Uimp):
Input Circuit / PE 8 kV
Rated Insulation Voltage (Ui):
Input Circuit / PE 1000 V
Degree of Protection:
Housing IP50
Terminals IP20
Housing IP50
Terminals IP20
Overvoltage Category:
III
Pollution Degree:
3
Connecting Capacity:
Flexible with Ferrule 1x 0.5 ... 2.5 mm²
Flexible with Ferrule 2x 0.5 ... 1.5 mm²
Flexible with Insulated Ferrule 1x 0.5 ... 2.5 mm²
Flexible with Insulated Ferrule 2x 0.5 ... 1.5 mm²
Flexible 1x 0.5 ... 2.5 mm²
Flexible 2x 0.5 ... 1.5 mm²
Rigid 1x 0.5 ... 4 mm²
Rigid 2x 0.5 ... 2.5 mm²
Flexible with Ferrule 1x 0.5 ... 2.5 mm²
Flexible with Ferrule 2x 0.5 ... 1.5 mm²
Flexible with Insulated Ferrule 1x 0.5 ... 2.5 mm²
Flexible with Insulated Ferrule 2x 0.5 ... 1.5 mm²
Flexible 1x 0.5 ... 2.5 mm²
Flexible 2x 0.5 ... 1.5 mm²
Rigid 1x 0.5 ... 4 mm²
Rigid 2x 0.5 ... 2.5 mm²
Tightening Torque:
0.6 ... 0.8 N·m
Wire Stripping Length:
8 mm
Recommended Screw Driver:
0.8 x 4
Mounting Position:
1 ... 6
Mounting on DIN Rail:
TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Standards:
CAN/CSA C22.2 No.14
IEC/EN 63000
IEC/EN 61326-2-4
IEC/EN 61557-1
IEC/EN 61557-8
UL 508
CAN/CSA C22.2 No.14
IEC/EN 63000
IEC/EN 61326-2-4
IEC/EN 61557-1
IEC/EN 61557-8
UL 508

Technical UL/CSA

Connecting Capacity UL/CSA:
Flexible 1x 18-14 AWG
Flexible 2x 18-16 AWG
Rigid 1x 20-12 AWG
Rigid 2x 20-14 AWG
Flexible 1x 18-14 AWG
Flexible 2x 18-16 AWG
Rigid 1x 20-12 AWG
Rigid 2x 20-14 AWG
Tightening Torque UL/CSA:
7.08 in·lb

Environmental

Ambient Air Temperature:
Operation -25 ... +60 °C
Storage -40 ... +85 °C
Operation -25 ... +60 °C
Storage -40 ... +85 °C
Maximum Operating Altitude Permissible:
Without Derating 2000 m

Material Compliance

Conflict Minerals Reporting Template (CMRT):
SCIP:
f62e7937-6dca-4f98-860f-3f06cc360129 Germany
Simplified SCIP:
f3269c7a-d8f2-4432-b5f7-f36b879d9097 Germany
5d3c3e58-ac44-4387-918a-5d7bc96e1cca Belgium
851cf05c-84a0-4855-9546-0e656ae4395a Portugal
6fd1ffb7-ed66-4b87-9180-d208f4c4d79b Bulgaria
2e526db7-5156-486c-9707-fdd843a63e8c Croatia
ca2ad8f5-e727-4c79-b58e-45c3d383e013 Estonia
a39c64f7-5ba4-488b-9da6-3f0535409c2b Netherlands
83c690dc-8fa6-4e8b-b036-b81a7cdfd3c4 Hungary
14efe67d-0174-4883-88fa-1ed9734fc463 Greece
dfb1cd65-c87e-45e6-93a3-7d5cf9daf2a6 Spain
a6146457-c276-41a8-af37-f1ae26feb6c8 Hungary
4fff6453-2464-45ff-befe-e7ee72b5adef Belgium
0f8db6e8-cfb4-47c1-9e48-46b503ecd7ab France
06638797-aba5-441b-89fb-133ecc2b6997 France
a2a6d230-37d7-4e9e-a1aa-a5a97285a8e4 Germany
251780c1-2325-4aae-a525-7383097c4078 Sweden
04c99ee7-3e91-4ddb-b532-491b004f2dfb Sweden
30c396a4-e48e-4d81-b897-e687b8d97b85 Poland
38ca4d92-27d6-46e2-ac6c-9d86371fa6d5 Poland
b78f9b6a-a325-4601-b9c6-839590bd267f Italy
1d2af833-e629-412b-835d-fb597871a88a Denmark
00807f1e-ddbb-4bf5-a86a-8c8f78222ed4 Czech Republic
88cc0d47-5679-411e-8254-c6d97715be1a Germany
31ee7fde-8a62-488b-949a-46547e0a9319 Germany
403ddb08-171f-4d09-bc40-f732ca04a977 Norway
17e7d567-1221-4bed-9a49-681ea6d0d673 Poland
da2b6944-fe5e-4af9-9c44-34eaf75db021 Finland
f3269c7a-d8f2-4432-b5f7-f36b879d9097 Germany
5d3c3e58-ac44-4387-918a-5d7bc96e1cca Belgium
851cf05c-84a0-4855-9546-0e656ae4395a Portugal
6fd1ffb7-ed66-4b87-9180-d208f4c4d79b Bulgaria
2e526db7-5156-486c-9707-fdd843a63e8c Croatia
ca2ad8f5-e727-4c79-b58e-45c3d383e013 Estonia
a39c64f7-5ba4-488b-9da6-3f0535409c2b Netherlands
83c690dc-8fa6-4e8b-b036-b81a7cdfd3c4 Hungary
14efe67d-0174-4883-88fa-1ed9734fc463 Greece
dfb1cd65-c87e-45e6-93a3-7d5cf9daf2a6 Spain

ABB EcoSolutions

ABB EcoSolutions:
Yes

Certificates and Declarations

CB Certificate:
cULus Certificate:

Container Information

Package Level 1 Units:
box 1 piece
Package Level 1 Width:
97 mm
Package Level 1 Depth / Length:
52.5 mm
Package Level 1 Height:
109 mm
Package Level 1 Gross Weight:
0.203 kg
Package Level 1 EAN:
4016779852630

External Classifications and Standards

Object Classification Code:
B
ETIM 7:
EC001444 - Insulation and earth fault monitoring relay
ETIM 8:
EC001444 - Insulation and earth fault monitoring relay
ETIM 9:
EC001444 - Insulation and earth fault monitoring relay
eClass:
V11.0 : 27371807
UNSPSC:
39122331
E-Number (Finland):
2712258
E-Number (Norway):
4187803
E-Number (Sweden):
3860658
Est. delivery between and
Estimated delivery dates are estimates only. Int'l customers allow a few more days. For more precise delivery estimates, please contact us at support@plc-direct.com. Contact us in advance for expedited shipping options.
Sale price$488.36
1-year warranty
FREE WORDWIDE SHIPPING
Condition:
$488.36
$397.63
$0.00
