1SVR550855R9400 ABB - CM-ENE MAX

Ordering

EAN:
4013614348099
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85364900

Dimensions

Product Net Width:
22.5 mm
Product Net Height:
78 mm
Product Net Depth / Length:
78.5 mm
Product Net Weight:
0.106 kg

Technical

Function:
Filling monitoring
Sub-Function:
Overflow protection
Number of Electrodes:
2
Measuring Range:
0 ... 100 kΩ
Rated Control Supply Voltage (Us):
24 V AC
Rated Frequency (f):
Supply Circuit 50/60 Hz
Output:
1 n/o contact
Terminal Type:
Screw Terminals
Rated Operational Current AC-12 (Ie):
(230 V) 4 A
Rated Operational Current AC-15 (Ie):
(230 V) 3 A
Rated Operational Current DC-12 (Ie):
(24 V) 4 A
Rated Operational Current DC-13 (Ie):
(24 V) 2 A
Rated Impulse Withstand Voltage (Uimp):
Measuring Circuit / Output Circuit 4 kV
Supply Circuit / Measuring Circuit 4 kV
Supply Circuit / Output Circuit 4 kV
Measuring Circuit / Output Circuit 4 kV
Supply Circuit / Measuring Circuit 4 kV
Supply Circuit / Output Circuit 4 kV
Rated Insulation Voltage (Ui):
Measuring Circuit / Output Circuit 250 V
Supply Circuit / Measuring Circuit 250 V
Supply Circuit / Output Circuit 250 V
Measuring Circuit / Output Circuit 250 V
Supply Circuit / Measuring Circuit 250 V
Supply Circuit / Output Circuit 250 V
Degree of Protection:
Housing IP50
Terminals IP20
Housing IP50
Terminals IP20
Short-Circuit Protective Devices:
Output Circuit NO - F Type Fuses 10 A
Connecting Capacity:
Flexible with Ferrule 2x 0.75 ... 1.5 mm²
Flexible 2x 1 ... 1.5 mm²
Rigid 2x 0.75 ... 1.5 mm²
Flexible with Ferrule 2x 0.75 ... 1.5 mm²
Flexible 2x 1 ... 1.5 mm²
Rigid 2x 0.75 ... 1.5 mm²
Tightening Torque:
0.6 ... 0.8 N·m
Wire Stripping Length:
10 mm
Mounting Position:
1 ... 6
Mounting on DIN Rail:
TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Standards:
CAN/CSA C22.2 No.14
IEC/EN 63000
IEC/EN 61000-6-2
IEC/EN 61000-6-3
UL 508
CAN/CSA C22.2 No.14
IEC/EN 63000
IEC/EN 61000-6-2
IEC/EN 61000-6-3
UL 508

Technical UL/CSA

Maximum Operating Voltage UL/CSA:
Output Circuit 300 V AC
Contact Rating UL/CSA:
B300
Connecting Capacity UL/CSA:
Flexible with Ferrule 2x 18-16 AWG
Flexible 2x 18-16 AWG
Rigid 2x 18-16 AWG
Flexible with Ferrule 2x 18-16 AWG
Flexible 2x 18-16 AWG
Rigid 2x 18-16 AWG
Tightening Torque UL/CSA:
7.08 in·lb

Environmental

Ambient Air Temperature:
Operation -20 ... +60 °C
Storage -40 ... +85 °C
Operation -20 ... +60 °C
Storage -40 ... +85 °C
Maximum Operating Altitude Permissible:
Without Derating 2000 m

Material Compliance

Conflict Minerals Reporting Template (CMRT):
SCIP:
df7a7df7-a3ec-429d-b9cb-42d0691c9aff Germany
Simplified SCIP:
2c275e2e-db45-4a4c-8eaa-140d21521fbe Finland
2eba3e89-6b14-468d-b01e-76cfbb0481df Poland
3bcd618a-e453-489f-9553-0fb7f3ee248d Belgium
bd1b2a1c-a4f3-45ec-9a30-b04ec4cae04e Germany
eb782991-dcd9-4148-9b8a-57c82ab74052 France
6d455b36-1f87-42d2-a073-52afc8421177 Belgium
a1390a09-54d5-4ccb-b282-4262d5d75695 Hungary
b4ffcb99-b679-4194-b493-e0ddc78fa2aa Bulgaria
982f0590-1fea-4fa6-9c9c-d1b5a561edbb Poland
a628b384-6e77-4dc3-9fa3-6393c0f38123 Denmark
4822f126-0a2f-4283-ab02-b99e0d16af55 Czech Republic
cfc4aa6c-0cb1-4be3-8626-6dac34ecd0d0 Germany
0e4f546a-f61b-4b42-ad2e-d62cc7bf06bf Italy
1ae65619-72fe-4d4c-aa08-ef2cd0978a3b Germany
be072f75-3808-4f51-bc44-042d14ff0fae Sweden
737feabc-152d-4d84-8bad-7d167d964517 Poland
a4128b97-3179-4850-a30f-e82d53707bb6 Norway
d09cbf6f-a7a7-4051-9794-ab229061449b Hungary
5053860e-d27e-41a4-a4db-7255b5f4188a Spain
5e6593e7-810c-4ab6-9081-60539ceeaee4 Croatia
49484e80-6df3-47ad-b075-40c3b29898fb Sweden
9fc1bffa-26a0-46b4-be5b-db41df6a0221 France
61541c68-ecf4-41b2-ab91-8c43f27ab583 Netherlands
ff816bbe-20ff-40a9-b753-6ba4ab9157d5 Greece
52613f35-d3dc-4261-b78b-0c942f4b67b9 Portugal
18bf7405-fd2a-4fc4-ae7e-edf5925f7050 Estonia
73a36fd5-787c-42b7-b651-ef2afa704326 Germany
2c275e2e-db45-4a4c-8eaa-140d21521fbe Finland
2eba3e89-6b14-468d-b01e-76cfbb0481df Poland
3bcd618a-e453-489f-9553-0fb7f3ee248d Belgium
bd1b2a1c-a4f3-45ec-9a30-b04ec4cae04e Germany
eb782991-dcd9-4148-9b8a-57c82ab74052 France
6d455b36-1f87-42d2-a073-52afc8421177 Belgium
a1390a09-54d5-4ccb-b282-4262d5d75695 Hungary
b4ffcb99-b679-4194-b493-e0ddc78fa2aa Bulgaria
982f0590-1fea-4fa6-9c9c-d1b5a561edbb Poland
a628b384-6e77-4dc3-9fa3-6393c0f38123 Denmark

Certificates and Declarations

CB Certificate:
cUL Certificate:

Container Information

Package Level 1 Units:
box 1 piece
Package Level 1 Width:
23 mm
Package Level 1 Depth / Length:
82 mm
Package Level 1 Height:
82 mm
Package Level 1 Gross Weight:
0.118 kg
Package Level 1 EAN:
4013614348099

External Classifications and Standards

Object Classification Code:
B
ETIM 7:
EC001447 - (Fill) level monitoring relay
ETIM 8:
EC001447 - (Fill) level monitoring relay
ETIM 9:
EC001447 - (Fill) level monitoring relay
eClass:
V11.0 : 27371813
UNSPSC:
39122331
E-Number (Finland):
2712851
E-Number (Norway):
4187269
E-Number (Sweden):
3860806
Price on request
