1SVR405622R3100 ABB - CR-U230AC3L
ABB

1SVR405622R3100 ABB - CR-U230AC3L

Ordering

EAN:
4013614498626
Minimum Order Quantity:
10 piece
Customs Tariff Number:
85364900

Dimensions

Product Net Width:
35 mm
Product Net Height:
54.4 mm
Product Net Depth / Length:
35 mm
Product Net Weight:
0.083 kg

Technical

Function:
Pluggable universal interface relay CR-U
Sub-Function:
Relay with built in LED
Rated Control Supply Voltage (Us):
230 V AC
Rated Operational Voltage:
250 V AC
Rated Frequency (f):
50 / 60 Hz
Output:
3 c/o (SPDT) contacts
Output Signal:
250 V / 10 A
Terminal Type:
Pin
Rated Operational Current AC-12 (Ie):
(230 V) 10 A
Rated Operational Current AC-15 (Ie):
(120 V) 3 A
(230 V) 1.5 A
(120 V) 3 A
(230 V) 1.5 A
Rated Operational Current DC-12 (Ie):
(24 V) 10 A
Rated Operational Current DC-13 (Ie):
(24 V) 2 A
(250 V) 0.1 A
(24 V) 2 A
(250 V) 0.1 A
Rated Insulation Voltage (Ui):
250 V
Degree of Protection:
IP40
Mounting Position:
1
Standards:
CAN/CSA C22.2 No.14
IEC/EN 63000
IEC/EN 61810-1
UL 508
CAN/CSA C22.2 No.14
IEC/EN 63000
IEC/EN 61810-1
UL 508

Technical UL/CSA

Maximum Operating Voltage UL/CSA:
300 V AC
Pilot Duty UL/CSA:
B300
Flammability According to UL94:
HB

Environmental

Ambient Air Temperature:
Operation -40 ... +55 °C
Storage -40 ... +85 °C
Operation -40 ... +55 °C
Storage -40 ... +85 °C
Maximum Operating Altitude Permissible:
Without Derating 2000 m

Material Compliance

Conflict Minerals Reporting Template (CMRT):
RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Certificates and Declarations

EAC Certificate:
RMRS Certificate:

Container Information

Package Level 1 Units:
box 10 piece
Package Level 1 Width:
182 mm
Package Level 1 Depth / Length:
77 mm
Package Level 1 Height:
76 mm
Package Level 1 Gross Weight:
0.87 kg
Package Level 1 EAN:
4013614374340

External Classifications and Standards

Object Classification Code:
K
ETIM 7:
EC001437 - Switching relay
ETIM 8:
EC001437 - Switching relay
ETIM 9:
EC001437 - Switching relay
eClass:
V11.0 : 27371601
UNSPSC:
39122331
E-Number (Finland):
2712798
E-Number (Norway):
4187493
E-Number (Sweden):
4005426
