ABB New Stock Image

1SDA067396R1 ABB

ABB EcoSolutions

ABB EcoSolutions:
Yes
ABB Site Meeting Group Waste To Landfill Target:
UL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions:
Recyclability Rate of the Product acc. to EN45555:
Design for Closing Resource Loops - Standard EN45555 - 55.9 %

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT):
Toxic Substances Control Act - TSCA:
SCIP:
62bbce4d-080f-4d86-9d81-b900472c629b Italy
Simplified SCIP:
479f51fc-294e-4dd6-895e-e829ac0b81e1 Poland
55b895cf-afa9-4baa-9ab8-1a4e51392550 France
2ff5a69b-4b7b-4aa0-aaca-580fc33c244a Sweden
c6d4ab2c-2876-4862-a074-95b19ec7a5db Germany
0564b919-5fdc-4fac-83de-b868b1cf479a Hungary
30e03275-97e9-43fd-950a-c41477e4f724 Hungary
3f2635c8-8b68-4411-83d9-38c9ab429218 Germany
b059d5cc-c10c-470b-b91a-8c5fba296910 Poland
352d50a8-6362-4006-aab7-149019f3a151 Netherlands
ddd923fd-da41-4ae8-91dc-fc97e42eee32 Bulgaria
9afe4ace-6b6c-49ee-9880-5a365d758903 Belgium
752d4914-a434-422a-bf45-6467cc38fa93 Spain
a1bdc34a-9ba6-4c5a-8124-e25737c8623e Sweden
59c45024-6b55-426e-939d-feef3baa0f33 Poland
76b7bfaf-8556-461f-9862-8cef9d327ecc Norway
99ecf823-5fdb-4e14-abf2-810261830484 Finland
7385ef91-2bd9-48a2-8c37-7dd4b14991c9 Belgium
d34e8069-d92d-4d9f-bce5-dfbd55f31e6d Germany
f93d3bb5-6874-4bfb-bc53-7426f177f77d Greece
264b5eaa-e9ff-4830-b97e-bc7991ec2f8c Portugal
abf903d0-ee30-4afb-bf25-aff4181635e9 Germany
6ac49de9-8f8e-476d-816d-1483a6ffa760 Croatia
0acc9fa6-ca0e-4ffb-b2ca-63b2beae6d3f Czech Republic
3e3ac273-7275-4ca1-b62e-88cce695e24b Germany
34880d7b-26c8-439a-b0c3-541a658baddc Estonia
eb832ab9-ab8e-4a4f-8384-e601ee2473be Denmark
479f51fc-294e-4dd6-895e-e829ac0b81e1 Poland
55b895cf-afa9-4baa-9ab8-1a4e51392550 France
2ff5a69b-4b7b-4aa0-aaca-580fc33c244a Sweden
c6d4ab2c-2876-4862-a074-95b19ec7a5db Germany
0564b919-5fdc-4fac-83de-b868b1cf479a Hungary
30e03275-97e9-43fd-950a-c41477e4f724 Hungary
3f2635c8-8b68-4411-83d9-38c9ab429218 Germany
b059d5cc-c10c-470b-b91a-8c5fba296910 Poland
352d50a8-6362-4006-aab7-149019f3a151 Netherlands
ddd923fd-da41-4ae8-91dc-fc97e42eee32 Bulgaria

Environmental

Environmental Information:

Ordering

Order Code US and Canada:
XT1CE3080AFF000XXX
E-Number (Finland):
3638627
E-Number (Norway):
4309616
EAN:
8015644695200
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85362090

Dimensions

Product Net Width:
76.2 mm
Product Net Height:
130 mm
Product Net Depth / Length:
70 mm
Product Net Weight:
1.1 kg

Container Information

Package Level 1 Units:
box 1 piece
Package Level 1 Width:
128 mm
Package Level 1 Height:
135 mm
Package Level 1 Depth / Length:
143 mm
Package Level 1 Gross Weight:
1.133 kg
Package Level 1 EAN:
8015644695200

Additional Information

Circuit Breaker Type to be Associated:
Power Distribution
Product Main Type:
SACE Tmax XT
Product Name:
Moulded Case Circuit Breaker
Product Type:
Automatic Circuit Breaker
Version:
F
CAD Dimensional Drawing:

Technical

Connecting Capacity Main Circuit:
Busbar 45.5 ... 80 mm²
Current Type:
AC/DC
Electrical Durability:
120 cycles per hour
8000 cycle
120 cycles per hour
8000 cycle
Mechanical Durability:
240 cycles per hour
25000 cycle
240 cycles per hour
25000 cycle
Number of Poles:
3P
Opening Time:
CB with SOR 30 ms
CB with UVR 30 ms
CB with SOR 30 ms
CB with UVR 30 ms
Order Multiple:
1 piece
Power Loss:
at Rated Operating Conditions per Pole 4.8 W
Rated Current (In):
80 A
Rated Frequency (f):
50 / 60 Hz
Rated Impulse Withstand Voltage (Uimp):
8 kV
Rated Instantaneous Short-Circuit Current Setting (Ii):
800 A
Rated Insulation Voltage (Ui):
800 V
Rated Operational Voltage:
690 V AC
500 V DC
690 V AC
500 V DC
Rated Service Short-Circuit Breaking Capacity (Ics):
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 12.5 kA
(500 V AC) 9 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
(500 V DC) 3 Poles in Series 25 kA
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 12.5 kA
(500 V AC) 9 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu):
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 25 kA
(500 V AC) 18 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
(500 V DC) 3 Poles in Series 25 kA
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 25 kA
(500 V AC) 18 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
Rated Uninterrupted Current (Iu):
160 A
Rated Voltage (Ur):
690 V
Recommended Screw Driver:
Main Circuit M6
Release:
TMD
Release Type:
TM
Setting Range:
56...80 A
Short-Circuit Performance Level:
C
Standards:
IEC60947-2
Sub-type:
XT1
Terminal Connection Type:
Front
Terminal Type:
Bolt
Tightening Torque:
6 N·m

Certificates and Declarations

ATEX Certificate:
Declaration of Conformity - CE:
GL Certificate:
LR Certificate:
UL Certificate:
VDE Certificate:
Dimension Diagram:
Mechanical Drawings:
Instructions and Manuals:

External Classifications and Standards

ETIM 9:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
Object Classification Code:
Q
UNSPSC:
39120000
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
eClass:
V11.1 : 27370409
Est. delivery between and
Estimated delivery dates are estimates only. Int'l customers allow a few more days. For more precise delivery estimates, please contact us at support@plc-direct.com. Contact us in advance for expedited shipping options.
$137.22
1-year warranty
FREE WORDWIDE SHIPPING
Condition:
$137.22
$0.00
