ABB Stock Image

1SBP260179R1001 ABB

Additional Information

ABB Type Designation:
CP555
Ambient Air Temperature:
Operation 0 ... +50 °C
Storage -20 ... +70 °C
Operation 0 ... +50 °C
Storage -20 ... +70 °C
Battery Type:
Portable
CN8:
84716070
Communication:
Depend on Driver
Communication Interface:
Ethernet with IFC ETTP
Communication Speed:
9.6 ... 57.6 kBd
Country or Territory of Origin:
France
Customs Tariff Number:
84716070
Data Sheet, Technical Information:
1SBC159001M6501
Declaration of Conformity - CE:
1SBD240567C1000
Degree of Protection:
IP65
Display Type:
TFT Touch
Environmental Information:
1SBD240179E1000
Fieldbus Interface Type:
Modbus RTUAC500_ModbusASCIIProfibus DP Slave (option)Modbus TCP_IPothers (contact us)
Frame Size:
Undefined
Fuse Size:
F6.3A
Fuse Type:
F6.3A
GSD-file for PROFIBUS Communication:
CP500_IFC-PBDP.gsd
Gross Weight:
3.1 kg
Instructions and Manuals:
1SBC159002M0202
Invoice Description:
CP555 Control Panel, CP500soft needed
Made To Order:
No
Memory Size:
1600 kB
Memory Size User Data:
1600 kB
Memory Size User Program:
1600 kB
Memory Type User Data:
1600 kilobyte non-volatile RAM
Memory Type User Program:
1600 KB Flash EPROM
Minimum Order Quantity:
1 piece
Mounting Type:
Front face
Mounting on DIN Rail:
No
Number of Characters Per Line:
20128
Number of Display Lines:
18120
Order Multiple:
1 piece
Power Consumption (@Pcons):
24 V·A
Power Supply:
24 V DC
Product Depth:
114 mm
Product Main Type:
CP555
Product Name:
Control Panel
Product Net Depth / Length:
105 mm
Product Net Height:
250 mm
Product Net Weight:
3 kg
Product Net Width:
290 mm
Product Type:
PLC-CP500
Profibus:
With IFC PBDP
Programming Software:
CP500 Soft
Quote Only:
No
Real-time Clock:
Yes
Release Type:
V1.02
Screen Color:
256 colors
Screen Resolution:
480 pixel
Screen Size:
10.4 in
Screen Type:
TFT touch
Security:
password protection with 8 user levels
Selling Unit of Measure:
piece
Serial Port 1 Type:
PR,MODBUS,ASCII,others
Serial Port 2 Type:
PR,MODBUS,ASCII,others
Service Life:
50000 hour
Short Description:
Control Panel Touch screen 256 Colors TFT Graphi
Short-Circuit Protective Devices:
gG Type Fuses Integrated
Software Function:
alarm managementrecipe managementtrends
Stocked At (Warehouses):
Menden, Germany
Supply Voltage:
20 ... 30 V DC
UL Certificate:
NRAG.E224886
USB Port 1 Type:
no
USB Port 2 Type:
no
Viewing Area Height:
158.4 mm
Viewing Area Length:
211.2 mm
WEEE B2C / B2B:
Business To Business
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
Est. delivery between and
Estimated delivery dates are estimates only. Int'l customers allow a few more days. For more precise delivery estimates, please contact us at support@plc-direct.com. Contact us in advance for expedited shipping options.
$5,304.78
1-year warranty
FREE WORDWIDE SHIPPING
Condition:
$0.00
$0.00
$5,304.78
Need More?
Ach Direct Debit American Express Apple Pay Diners Club Discover Google Pay Mastercard PayPal Shop Pay Visa
