The ABB MS116-1.6 is a compact manual motor starter, also known as a motor protection circuit breaker or manual motor protector, with a 45 mm module width and rated operational current of 1.6 A. The device is designed to manually switch motors on and off while providing reliable protection against short-circuits, overload, and phase failures without requiring additional fuses. It features thermal and electromagnetic protection with trip class 10A and a rated service short-circuit breaking capacity of 50 kA at 400 VAC. The unit includes built-in disconnect function, temperature compensation, trip-free mechanism, and a rotary handle with clear switch position indication. It is suitable for three-phase and single-phase motor applications up to 0.55 kW at 400 V and offers 6 kV impulse protection. DIN rail mountable with screw terminals for easy installation.
Item Details
- Brand Name: ABB
- Manufacturer: ABB
- Item Type Name: Manual Motor Starter
- Product Family / Series: MS116
- Model: MS116-1.6
- Part Number: 1SAM250000R1006
Product Specifications
- rated_operational_current: 1.6 A
- adjustment_range: 1.0 - 1.6 A
- rated_power_400V: 0.55 kW
- rated_power_480V_UL: 0.75 HP
- voltage_range: 208 - 690 V AC
- short_circuit_breaking_capacity: 50 kA at 400 V AC
- trip_class: 10A
- impulse_withstand_voltage: 6 kV
- poles: 3
- protection_degree: IP20
- mounting: DIN rail
- terminal_type: Screw terminals
- switching_cycles_electrical: 100,000 cycles
- switching_cycles_mechanical: 100,000 cycles
Additional Details
- Country of Origin*: DE
- Certifications / Approvals: UL E137861, CSA 165767
- Rohs Status: Exempt
- Max Operating Altitude: 2000 m
*Country of origin may vary.
Measurements
- Weight: 0.265 kg
- Dimensions: 90 x 45 x 80.1 mm
- Width: 45 mm
