Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Protection accessories |
| Accessory / Separate Part Type | Isolation unit |
| Accessory / separate part designation | Serial link isolation unit with USB hub |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGT2... XBTGT7340 XBTGT6... XBTOT... XBTGK.... XBTGT4... XBTGT5... |
| Range Compatibility | Harmony HMI GTO |
| Electrical connection | 1 female connector SUB-D 9 1 male connector SUB-D 9 |
| Physical interface | RS485 RS232C |
This Magelis XBTZ is a mechanical adaptor for substitution of terminals of the Magelis range. This accessory enables substitution from From XBTG2110 to XBTGT2xx0. It is a mounting accessory for the Magelis XBTGT advanced touchscreen panel.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Adaptation accessories |
| Accessory / Separate Part Type | Adaptor |
| Accessory / separate part designation | Mechanical adaptor for substituting XBTG2110 by XBTGT2..0 |
| Accessory / separate part destination | Advanced panel |
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Connection accessories |
| Accessory / Separate Part Type | Connector |
| Accessory / separate part designation | Auxiliary connector |
| Accessory / separate part destination | Advanced panel |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGT4. XBTGT5. XBTGT7. XBTGK5. XBTGT6. |
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Connection accessories |
| Accessory / Separate Part Type | Connecting cable |
| Accessory / separate part designation | Direct connection cable |
| Accessory / separate part destination | XBT terminal |
| Cable length | 8.2 ft (2.5 m) |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTR411 XBTN410 XBTNU400 XBTN401 XBTR410 |
| Range Compatibility | Harmony HMI GTO Allen-Bradley PLC5 |
| Electrical connection | 2 male connectors SUB-D 25 |
| Communication Port Protocol | DF1 |
| Physical interface | RS232 |
| Product Weight | 0.46 lb(US) (0.21 kg) |
This Magelis XBTZ is a RS 422 cable for connecting Magelis terminals to third-party PLCs. It enables connection of XBTGH and XBTGT terminals to Mitsubishi Melsec PLC with XBTZGCOM1 adaptor. It is equipped with one 9-way SUB-D connector at one end and one free end at the other end, it is 5 meters long.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Connection accessories |
| Accessory / Separate Part Type | Connecting cable |
| Accessory / separate part designation | Cable for 2-port adaptor |
| Accessory / separate part destination | Connection of XBT terminal to Mitsubishi Melsec PLC with XBTZGCOM1 adaptor |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGK.... XBTGT4... XBTGT6... XBTGT2... XBTOT... XBTGT5... XBTGT7340 |
| Range Compatibility | Mitsubishi FX Mitsubishi QnA CPU Harmony HMI GTO Mitsubishi A CPU |
| Cable length | 16.4 ft (5 m) |
| Electrical connection | 1 connector SUB-D 9 Free end |
| Communication Port Protocol | QnA CPU (SIO) A CPU (SIO) FX (CPU) |
| Physical interface | RS422 |
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Adaptation accessories |
| Accessory / Separate Part Type | Adaptor |
| Accessory / separate part designation | Adaptor for terminal XBT |
| Accessory / separate part destination | Small and advanced panel |
| Cable length | 0.7 ft (0.2 m) |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGK.... HMIGTO XBTRT... XBTGT.... |
| Electrical connection | 1 connector RJ45 terminal side) 1 connector SUB-D 25 automation product side) |
| Physical interface | RS232C/RS485 |
Magelis XBT - universal cable RS422 - for XBTGK, XBTGT, XBTOT - 2.5 m
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Adaptation accessories |
| Accessory / Separate Part Type | Adaptor cable |
| Accessory / separate part designation | Adaptor cable |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGT2000 XBTGT4000 XBTGT5000 XBTGT7000 XBTGT6000 HMIGTO |
Magelis XBT - direct connection cable - 5 m - 1 male connector SUB-D 25/SUB-D 9
Magelis XBT - direct connection cable - for XBTGK, XBTGT, XBTOT - 5 m
This Magelis XBTZ is an adaptor for Magelis terminal. It can be used with the connection cable depending on the application concerned. It is equipped with one 25-way SUB-D connector and one 9-way SUB-D connector, RS 485 on XBT terminal and 0.2 meter cable. It can be used to connect a controller to the XBTGT terminal.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Adaptation accessories |
| Accessory / Separate Part Type | Adaptor |
| Accessory / separate part designation | Adaptor for terminal XBT |
| Accessory / separate part destination | Advanced panel |
| Cable length | 0.7 ft (0.2 m) |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGTW... XBTGT6... XBTOT... XBTGT5... HMIGTO XBTGT4... XBTGK.... XBTGT2... XBTGT7... |
| Electrical connection | 1 connector SUB-D 25 automation product side) 1 connector SUB-D 9 terminal side) |
| Physical interface | RS485 |
Modbus serial link for XBT terminal - L = 2.5 m - 1 male RJ45
This Magelis XBTZ is a RS 232C cable for connecting Magelis terminals to third-party PLCs. It enables direct connection of XBTGH / XBTGT and GTO / GTU terminals to Mitsubishi Melsec PLC. It is equipped with one 9-way SUB-D connector at each end, it is 5 meters long.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Connection accessories |
| Accessory / Separate Part Type | Connecting cable |
| Product or Component Type | Connecting cable |
| Accessory / separate part designation | Direct connection cable |
| Accessory / separate part destination | Direct connection of XBT terminal to Mitsubishi Melsec PLC |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGK.... XBTGTW... XBTGT6... XBTGT4... XBTGT7340 XBTOT... XBTGT2... XBTGT5... |
| Range Compatibility | Harmony HMI GTO Mitsubishi Q Link |
| Cable length | 16.4 ft (5 m) |
| Electrical connection | 2 male connectors SUB-D 9 |
| Communication Port Protocol | Q Link (SIO) |
| Physical interface | RS232C |
This Magelis XBTZ is an USB gateway for Magelis terminal. It enables the connection of Magelis terminals to Modbus Plus fieldbus. This product is compatible with Magelis XBTGK, XBTGT and XBTGTW.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Communication accessories |
| Accessory / Separate Part Type | Gateway |
| Accessory / separate part designation | USB gateway |
| Accessory / separate part destination | Terminal |
| Bus type | Modbus Plus |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGK.... XBTGT.... XBTGTW... |
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Connection accessories |
| Accessory / Separate Part Type | Connecting cable |
| Accessory / separate part designation | Direct connection cable |
| Accessory / separate part destination | XBT terminal |
| Cable length | 8.2 ft (2.5 m) |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTR411 XBTN410 XBTNU400 XBTN401 XBTR410 |
| Range Compatibility | Harmony HMI GTO Allen-Bradley SLC5, 1761NETAIC |
| Electrical connection | 1 male connector SUB-D 25 1 male connector SUB-D 9 |
| Communication Port Protocol | DF1 |
| Physical interface | RS232 |
| Product Weight | 0.46 lb(US) (0.21 kg) |
This Magelis XBTZ is a RS 485 cable for connecting Magelis terminals to third-party PLCs. It enables direct connection of XBTGH / XBTGT and GTO / GTU terminals to Siemens, Simatic PLCs. It is equipped with one RJ45 male connector at one end and one 9-way male SUB-D connector at the other end. It complies with Siemens PPI protocol. it is 2.5 meters long.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Connection accessories |
| Accessory / Separate Part Type | Connecting cable |
| Accessory / separate part designation | Direct connection cable |
| Accessory / separate part destination | Direct connection of XBT terminal to Siemens Simatic PLC Small touch screen panel |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGT6... XBTGT5... XBTRT500 XBTRT511 XBTGK.... XBTGT4... XBTGT1... XBTGT7340 XBTGT2... |
| Range Compatibility | Harmony HMI GTO Siemens S7-400 Siemens S7-200 Siemens S7-300 Harmony STO & STU |
| Cable length | 8.2 ft (2.5 m) |
| Electrical connection | 1 male connector RJ45 1 male connector SUB-D 9 |
| Communication Port Protocol | PPI MPI |
| Physical interface | RS485 |
This Magelis XBTZ is an application transfer cable between Magelis terminal and PC. It is a separate component for the Magelis XBTGC / GT / GK advanced panels and Magelis STO / STU small panels. It is equipped with one USB male connector, terminal side and one USB male type A connector, peripheral side. It is 2.5 meters long.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Connection accessories |
| Accessory / Separate Part Type | Connecting cable |
| Accessory / separate part designation | Application transfer cable between terminal and PC |
| Accessory / separate part destination | Advanced panel 3.5" small touch screen panel 3.4" small touch screen panel |
| Cable length | 8.2 ft (2.5 m) |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTOT... XBTGK.... XBTGT6... HMIGTO XBTGT5... HMISTO XBTGTW... HMISTU XBTGT4... XBTGT1..5 XBTGT7... XBTGT2... |
| Electrical connection | 1 male connector USB 1 male connector USB terminal side) |
| Communication port support | TTL |
Main
| Characteristic | Value(s) |
|---|---|
| Accessory / separate part category | Connection accessories |
| Accessory / Separate Part Type | Connecting cable |
| Accessory / separate part designation | Discrete I/O connecting cable |
| Accessory / separate part destination | 3.8" screen HMI controller |
| Range Compatibility | Advantys Telefast ABE7 Magelis XBT GC, GT/GK with control |
Complementary
| Characteristic | Value(s) |
|---|---|
| Cable length | 6.6 ft (2 m) |
| Electrical connection | 1 connector HE10, 26 ways Telefast ABE7 side 1 connector, 22 ways controller side |
| Product Weight | 0.40 lb(US) (0.18 kg) |
Magelis XBT - set of 2 adaptors for USB cable
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Connection accessories |
| Accessory / Separate Part Type | Connecting cable |
| Accessory / separate part designation | Direct connection cable |
| Accessory / separate part destination | Small touch screen panel |
| Cable length | 8.2 ft (2.5 m) |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTRT511 XBTRT500 |
| Range Compatibility | Harmony HMI GTO Omron CPM1, CPM2, CJ1, CS1 Harmony STO & STU |
| Electrical connection | 1 male connector SUB-D 9 |
| Communication Port Protocol | Sysmacway |
| Physical interface | RS232 |
This Magelis XBTZ is a mechanical adaptor for substitution of terminals of the Magelis range. This accessory enables substitution from: XBTGT5230 to HMIGTO5310, XBTGT5230 to HMIDT542, and XBTG5330 to XBTGT5330. It is a mounting accessory for the Magelis XBTGT and Magelis GTO / GTU panels.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Adaptation accessories |
| Accessory / Separate Part Type | Adaptor |
| Accessory / separate part designation | Mechanical adaptor for substituting XBTG5330 by XBTGT5330 |
| Accessory / separate part destination | Advanced panel |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | HMIGTO5310 |
This Magelis XBTZ is a remote USB type A port location for Magelis terminal. It enables the USB port to be located remotely on the rear of the HMI terminal on a panel or cabinet door. It has 1 meter cable length and 21mm fixing hole diameter.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Protection accessories |
| Accessory / Separate Part Type | Remote USB port |
| Accessory / separate part designation | Remote USB port |
| Accessory / separate part destination | 3.5" small touch screen panel Advanced panel 3.4" small touch screen panel |
| Cable length | 3.3 ft (1 m) |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGT6... XBTGT1..5 XBTGT4... XBTOT... XBTGT7... XBTGT2... XBTGK.... HMISTO HMIGTO XBTGT5... XBTGTW... HMISTU |
| Connector Type | USB type A |
| Product Weight | 0.49 lb(US) (0.22 kg) |
This Magelis XBTZ is an extension connector protection for terminals of Magelis range. It is a connection accessory for Magelis XBTGT advanced touchscreen panels.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Magelis XBT |
| Accessory / separate part category | Protection accessories |
| Accessory / Separate Part Type | Connector protection |
| Accessory / separate part designation | Extension connector protection |
| Accessory / separate part destination | Advanced panel |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGT3... XBTGT6... XBTGT5... XBTGT4... XBTGT7... XBTGT2... XBTOT... XBTGK.... |
| Product Weight | 0.07 lb(US) (0.03 kg) |
This Magelis XBTZ is a RS 232 cable for Modbus serial link. It enables direct connection between Magelis XBT terminals and distributed I/Os. It is equipped with one HE-13 connector at one end and one 25-way male SUD-D connector at the other end. it is 2.5 meters long. It is compatible with Modicon Modicon STB modular distributed I/Os.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Connection accessories |
| Accessory / Separate Part Type | Connecting cable |
| Accessory / separate part designation | Direct connection cable |
| Accessory / separate part destination | XBT terminal |
| Cable length | 8.2 ft (2.5 m) |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGT.... XBTGTW... XBTGK.... XBTR411 XBTN410 XBTNU400 XBTN401 XBTR410 |
| Range Compatibility | Harmony HMI GTO Advantys STB distributed I/O solutions |
| Electrical connection | 1 male connector SUB-D 25 1 connector HE-13 |
| Communication Port Protocol | Modbus |
| Physical interface | RS232 |
| Product Weight | 0.37 lb(US) (0.17 kg) |
