MVI69-HART Prosoft

The MVI69-HART Multi-drop Master Communication Module is designed to allow CompactLogix / MicroLogix processors to interface easily with HART compatible devices. Devices commonly supporting the protocol include pressure, temperature, flow transmitters, as well as other similar instruments commonly found in the process (and other) industry. The MVI69-HART Master Communication Module allows Rockwell Automation CompactLogix / MicroLogix compatible processors to easily communicate with HART slave devices. The MVI69-HART module interfaces up to 15 devices on each HART channel with the processor. HART channels on the module support Master protocol commands to interface with slave devices on their own networks. Each port is individually configurable. Data is exchanged between the HART network and the CompactLogix / MicroLogix processor backplane using the internal database contained in the module and direct control by the processor’s ladder logic and pre-defined data objects (5000 registers maximum). The MVI69-HART module is the perfect solution for industrial applications in chemical and refining operations, gas and liquid distribution systems, and remote offshore monitoring stations, addressing virtually all aspects of control, data acquisition, and maintenance. HART® is a registered trademark of the HART Communication Foundation.
