The SpaceLogic AS-P-NL server is at the core of an EcoStruxure BMS and performs key functionality. The server performs functionality such as control logic, trend logging and alarm supervision. It supports communication and connectivity to the I/O and field buses. The SpaceLogic AS-P server can act as a standalone server, control I/O modules, monitor and manage field bus devices. This model features two ethernet ports, two RS-485 ports, one I/O bus port, one USB device port and one USB host port. Its dimensions are 114 mm (4.5 in.) in height, 90 mm (3.6 in.) in width and 64 mm (2.5 in.) in depth. Plastic flame rating is UL94-5VB and the ingress protecton rating is IP20. A terminal base TB-ASP-W1 is required for each SpaceLogic AS-P.
Main
| Characteristic | Value(s) |
|---|---|
| Product or Component Type | Network Controller |
| Backup Time | 10 days |
| Model | AS-P-NL |
| Product Certifications | BTL B-BC cUL Listed UL Listed RCM |
| Clock Drift | +/- 52 s/month |
| Color | Black |
| Communication Service | TLS 1.0 |
| Device short name | AS-P-NL |
| Flame Retardance | UL94-5VB |
| Power Consumption in W | 10 W |
| IP Degree of Protection | IP20 |
| Mounting Mode | DIN Rail Mount |
| Network Frequency | 50 Hz 60 Hz |
| Depth | 2.5 in (64 mm) |
| Height | 4.5 in (114 mm) |
| Product Weight | 0.708 lb(US) (0.321 kg) |
| Width | 3.5 in (90 mm) |
| Ambient air temperature for operation | 32â¦122 °F (0â¦50 °C) |
| Ambient Air Temperature for Storage | -4â¦158 °F (-20â¦70 °C) |
| Memory Type | 4 GB flash 512 MB RAM |
| Standards | EN 61000-6-2 EN 50491-5-3 EN 60730-1 EN 60730-2-11 EN 50491-3 UL 916 EN 50491-1 EN 61000-6-3 EN 50491-5-2 FCC part 15 Subpart B class B |
| Communication Port Support | ETHERNET 10/100BASE-TX |
| Number of Port | 2 RJ45 1 USB device port Mini-B 1 USB host port type A 2 RS485 |
| [Us] Rated Supply Voltage | 24 V AC 24 V DC |
| Maximum Number of Connected Devices | 464 |
Complementary
| Characteristic | Value(s) |
|---|---|
| Communication port protocol | BACnet HTTP HTTPS Modbus TCP serial line master or slave TCP (Transmission Control Protocol) |
