The SICK WTB27-3P2441 is a compact photoelectric proximity sensor from the W27 product family, designed for diffuse reflection sensing with background suppression. It employs a visible red LED light source at 660 nm wavelength for reliable object detection across a sensing range of 30 mm to 1,100 mm. The sensor features PNP complementary switching output with light/dark switching capability, and offers potentiometer-based sensitivity adjustment for precise detection of multi-colored objects. Built in a rectangular ABS plastic housing with IP69K enclosure rating, it provides robust performance in harsh industrial environments with operating temperatures from -40°C to +60°C. The M12 4-pin male connector ensures easy installation and integration into automation systems. With a fast response time of 1.5 ms and switching frequency up to 350 Hz, the sensor is well-suited for high-speed detection applications in manufacturing, material handling, packaging, and general industrial automation.
Item Details
- Brand Name: Sick
- Manufacturer: Sick
- Item Type Name: Photoelectric Proximity Sensor
- Product Family / Series: W27
- Part Number: WTB27-3P2441
- Alternate Part Number: 1027744
- Sensing Principle: Photoelectric diffuse reflection with background suppression
Product Specifications
- sensing_range: 30 mm to 1,100 mm
- light_source: Red LED
- wavelength: 660 nm
- light_spot_size: Ø 15 mm at 500 mm distance
- supply_voltage: 10 V DC to 30 V DC
- current_consumption: 35 mA
- output_type: PNP complementary
- switching_function: Light/dark switching
- signal_voltage: Approx. VS - 2.5 V / 0 V
- output_current_max: 100 mA
- response_time: ≤ 1.5 ms
- switching_frequency: 350 Hz
- connection_type: M12 4-pin male connector
- adjustment_method: Potentiometer
- enclosure_rating: IP69K
- ambient_operating_temperature: -40 °C to +60 °C
- ambient_storage_temperature: -40 °C to +75 °C
- ripple: < 5 Vpp
- protection_class: II
- circuit_protection: VS connections reverse-polarity protected, inputs and output reverse-polarity protected, interference suppression
Additional Details
- Lifecycle Status: Discontinued
- Certifications / Approvals: UL File No. NRKH.E181493 & NRKH7.E181493
Measurements
- Weight: 100 g
- Dimensions: 24.6 x 80.6 x 54 mm
