1 year warranty
Redundant HSBY processor module M580 - Level 4 - Remote
Redundant Processor, Modicon M580, 64Mb, 61 Ethernet Devices, 31 Remote Io Racks Of X80 And Quantum Io
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Modicon Quantum automation platform |
| Product or Component Type | Unity processor |
Complementary
| Characteristic | Value(s) |
|---|---|
| Mode of Transmission | Multi mode |
| Clock frequency | 266 MHz |
| Number of slots | 10 16 4 6 2 |
| Number of racks | 2 - local |
| Number of distributed I/O station | 63 1 3 Modbus Plus |
| Number of remote I/O station | 31 - 2 S908 remote I/O 31 - 2 ethernet Quantum remote I/O 31 - 2 ethernet X80 remote I/O |
| Discrete I/O number | 31744 inputs, 31744 outputs - remote 8000 inputs, 8000 outputs - distributed - per network Modbus Plus Unlimited (31 drops of 28 slots max) - ethernet remote I/O 0 - local - forbidden in Hot Standby application |
| Analogue I/O number | 500 inputs, 500 outputs - distributed - per network Modbus Plus Unlimited (31 drops of 28 slots max) - ethernet remote I/O 1984 inputs,1984 outputs - remote 0 - local - forbidden in Hot Standby application |
| Application specific I/O | Accurate time stamping Counter Serial link High-speed interrupt inputs |
| Communication Service | Ethernet router |
| Number of optional modules | 6 Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max) |
| Maximum number of connections | 1 USB 2 AS-Interface - distributed 4 AS-Interface - remote 6 Ethernet TCP/IP - local 6 Modbus Plus - local 6 Profibus DP - local 1 Modbus RS232/485 Modbus/ASCII) |
| Integrated connection type | 1 Modbus Plus 1 Modbus 1 USB 1 optic fibre Hot Standby |
| Checks | Process control Hot standby |
| Memory description | Expandable 7168 kB - program with PCMCIA card Expandable 8 MB - file storage with PCMCIA card Internal RAM 3072 kB - 1536 kB for data |
| Switch Function | Key switch memory port on/off |
| Application structure | 1 periodic fast task - forbidden in Hot Standby application 128 I/O interrupt tasks - forbidden in Hot Standby application 128 interrupt tasks - forbidden in Hot Standby application 32 timer interrupt tasks - forbidden in Hot Standby application 4 auxiliary tasks - forbidden in Hot Standby application 1 cyclic/periodic master task - |
| Number of instructions per ms | 10.28 Kinst/ms 100 % Boolean 10.07 Kinst/ms 65 % Boolean and 35 % numerical |
| System overhead | 0.2 ms fast task 1 ms master task |
| Bus current requirement | 2760 mA |
| Local signalling | for Ethernet activity (COM) 1 LED (yellow) 1 LED (yellow) for configuration status (STS) |
| Electrical connection | 1 female connector SUB-D 9 for connecting to the Modbus Plus network 1 connector RJ45 for connecting Modbus bus 1 connector MT-RJ (multimode fiber optic) for interconnecting primary and secondary PLCs up to 4 km |
redundant processor, Modicon M580, 8MB, 61 Ethernet devices, 8 local racks, 8 remote IO racks
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Modicon Premium Automation platform |
| Product or Component Type | Ethernet TCP/IP module |
| Physical interface | RJ45 - 10BASE-T/100BASE-TX 1 twisted pair |
| Transmission rate | 10/100 Mbit/s |
| Communication service | Bandwidth management FDR server Global Data I/O scanning Modbus TCP messaging SMTP e-mail notification SNMP agent Uni-TE messaging |
| Supply | Via the power supply of the rack |
| Local signalling | 1 LED for collision detection (COL) 1 LED for Ethernet network status (RUN) 1 LED for Ethernet port fault (ERR) 1 LED for transmission/reception activity (TX/TR) |
Complementary
| Characteristic | Value(s) |
|---|---|
| Communication Port Protocol | Modbus TCP Uni-Telway |
| Maximum number of connections | 64 |
| Web server | Transparent ready class B30 |
| web feature | Rack viewer Data Editor (via PC terminal) |
| Marking | CE |
| Product compatibility | PL7 Pro Unity Pro |
| Current consumption | 360 mA 5 V DC |
| Module format | Standard |
| Product Weight | 0.75 lb(US) (0.34 kg) |
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Modicon Premium Automation platform |
| Product or Component Type | Ethernet TCP/IP module |
| Physical interface | RJ45 - 10BASE-T/100BASE-TX 1 twisted pair |
| Transmission rate | 10/100 Mbit/s |
| Communication service | Bandwidth management FDR server Global Data I/O scanning Modbus TCP messaging SMTP e-mail notification SNMP agent Uni-TE messaging |
| Supply | Via the power supply of the rack |
| Local signalling | 1 LED for collision detection (COL) 1 LED for Ethernet network status (RUN) 1 LED for Ethernet port fault (ERR) 1 LED for transmission/reception activity (TX/TR) |
Complementary
| Characteristic | Value(s) |
|---|---|
| Communication Port Protocol | Modbus TCP Uni-Telway |
| Maximum number of connections | 64 |
| Web server | Transparent ready class B30 |
| web feature | Rack viewer Data Editor (via PC terminal) |
| Marking | CE |
| Product compatibility | PL7 Pro Unity Pro |
| Current consumption | 360 mA 5 V DC |
| Module format | Standard |
| Product Weight | 0.75 lb(US) (0.34 kg) |
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Modicon Quantum automation platform |
| Product or Component Type | Unity processor |
Complementary
| Characteristic | Value(s) |
|---|---|
| Clock frequency | 166 MHz |
| Number of slots | 10 16 6 4 2 |
| Number of racks | 2 - local |
| Number of distributed I/O station | 63 1 3 Modbus Plus |
| Number of remote I/O station | 31 - 2 S908 remote I/O 31 - 2 ethernet Quantum remote I/O 16 - 2 ethernet X80 remote I/O |
| Discrete I/O number | 31744 inputs, 31744 outputs - remote 8000 inputs, 8000 outputs - distributed - per network Modbus Plus Unlimited (26 slots max) - local Unlimited (31 drops of 28 slots max) - ethernet remote I/O |
| Analogue I/O number | 500 inputs, 500 outputs - distributed - per network Modbus Plus 1984 inputs,1984 outputs - S908 remote I/O Unlimited (26 slots max) - local Unlimited (31 drops of 28 slots max) - ethernet remote I/O |
| Application specific I/O | Accurate time stamping Serial link High-speed interrupt inputs Counter |
| Communication Service | Ethernet router |
| Number of optional modules | 6 Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max) |
| Maximum number of connections | 1 USB 2 AS-Interface - distributed 4 AS-Interface - remote 6 Ethernet TCP/IP - local 6 Modbus Plus - local 6 Profibus DP - local 1 Modbus RS232/485 Modbus/ASCII) |
| Integrated connection type | 1 Modbus Plus 1 Ethernet TCP/IP 1 Modbus 1 USB |
| Checks | Process control |
| Memory description | Expandable 7168 kB - program with PCMCIA card Expandable 8 MB - file storage with PCMCIA card Internal RAM 768 kB |
| Switch Function | Key switch memory port on/off |
| Application structure | 1 cyclic/periodic master task - 1 periodic fast task - 128 I/O interrupt tasks - 128 interrupt tasks - 32 timer interrupt tasks - 4 auxiliary tasks - |
| Number of instructions per ms | 10.28 Kinst/ms 100 % Boolean 10.07 Kinst/ms 65 % Boolean and 35 % numerical |
| System overhead | 0.2 ms fast task 1 ms master task |
| Bus current requirement | 2160 mA |
| Local signalling | 1 LED (green) for Ethernet activity (COM) 1 LED (red) for Ethernet collision |
| Electrical connection | 1 female connector SUB-D 9 for connecting to the Modbus Plus network 1 connector RJ45 for connecting Ethernet network 1 connector RJ45 for connecting Modbus bus |
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Modicon Quantum automation platform |
| Product or Component Type | Ethernet network TCP/IP module |
| Concept | Transparent Ready |
| Web server | Class C30 |
| Web services | Rack viewer FactoryCast configurable Data editor |
| Communication Service | Bandwidth management NTP time synchronization SNMP network management I/O scanning Modbus TCP messaging SMTP e-mail notification FDR server Global Data |
| Communication Port Protocol | Ethernet Modbus TCP/IP |
| Physical interface | MT/RJ - 100BASE-FX fiber optic RJ45 - 10BASE-T/100BASE-TX twisted pair |
| Transmission Rate | 10/100 Mbit/s |
Complementary
| Characteristic | Value(s) |
|---|---|
| Redundancy | Yes hot standby redundant architecture |
| Supply | Via the power supply of the rack |
| Marking | CE |
| Local signalling | 1 LED for 10 Mbps or 100 Mbps data rate (10 MB/100 MB) 1 LED for collision detection (Coll) 1 LED for download mode (Kernel) 1 LED for Ethernet module fault (Fault) 1 LED for Ethernet network status (RUN) 1 LED for full-duplex mode (Fduplex) 1 LED for module ready (Ready) 1 LED for network active (Link) 1 LED for rack operational (Active) 1 LED for transmission/reception activity (TxAct/RxAct) |
| Current consumption | 750 mA 5 V DC |
| Module format | Standard |
| Product Weight | 0.761 lb(US) (0.345 kg) |
TeSys F contactor - 3P(3 NO)-AC-3 <= 440V 630 A with coil LX1/ LX9 - 481000V AC 40/400Hz, LX4 - 48...440V DC
This Lexium 32 Servo Drive Works At A Rated Supply Voltage From 208V Ac To 480V Ac. It Can Feed 3-Phase Synchronous Motors Bmh Or Bsh, Its Continuous Output Current Is 24A At 8Khz. The Compact Size Of The Servo Drive And Associated Servo Motor Provides Maximum Power In The Minimum Space. This Servo Drive Is Specifically Designed For Industrial Machines. It Offers High Performance, Power And Simplicity Of Use In Motion Control Applications. It Complies With International Standards Iec/En 61800-5-1, Iec/En 61800-3, And Is Ul And Csa And Is Ul And Csa Certified And Ce Marked. It Has Been Developed To Meet The Requirements Of Directives Regarding Protection Of The Environment (Ro
The PowerLogic PM8000 series meters are compact, cost-effective multifunction power meters that will help you ensure reliability and efficiency of your power-critical facility. They reveal and provide understanding of complex power quality conditions enabling action to be taken to mitigate any issue. The PowerLogic PM8000 series meters have the versatility to perform nearly any job you need a meter to do, wherever you need it! The modular, flexible ION technology architecture enables a simple, building block approach for customizing each meter to any application. With patented Disturbance Direction Detection, revenue grade accuracy, multiple communication ports, onboard power quality analysis, web interface and a color graphical display. Certified by third party labs for energy accuracy (IEC 62052-11, IEC 62052-22, IEC 62052-24) and power quality (IEC 62586-2, IEC 61000-4-30 Class S). The PowerLogic PM8000 series provides data quality confidence you can count on. Cybersecurity features include secure protocols (HTTPS, SFTP), security event logging, Syslog protocol. Ability to enable/disable communication ports, and 50 user configurable accounts. With 512 MB of memory to support 50 data logs, 50+ user-definable alarms, waveform captures, 1/2 cycle RMS logging, custom web pages, min/max logs, energy trends, and Time of Use. The ability to timestamp events to +/-1 ms utilizing time synchronization method that include PTP (IEEE1588), NTP, IRIG-B, GPS ASCII (RS485) and network time set function. 3 digital inputs and one digital output, plus the ability to add up to 4 option modules. I/O option modules include 2 relays and 6 digital inputs or 2 analog outputs and 4 analog inputs. Wide control power range of 90-415 VAC / 110-415 VDC. Operating environment of -25 to +70C; Humidity rating of 5% to 95%; Altitude up to 3000 m. Panel mounting (1/4 DIN) with integrated display.
Main
| Characteristic | Value(s) |
|---|---|
| Range | PowerLogic |
| product name | PowerLogic PM8000 |
| Product or Component Type | Power meter |
| Device short name | PM8240 |
| Market segment | Buildings large building cost management: billing: sub feeder Buildings small building network management: main incomer Buildings medium building network management: main incomer Buildings large building network management: main incomer Buildings large building network management: sub feeder Buildings multi-site network management: main incomer Buildings multi-site network management: sub feeder Data center network management: main incomer Data center network management: sub feeder Healthcare network management: main incomer Healthcare network management: sub feeder Industry network management: main incomer Industry network management: sub feeder Utility: sub feeder |
| model type | Standard |
Complementary
| Characteristic | Value(s) |
|---|---|
| Power quality analysis | EN 50160 2010 compliance report IEEE 519 2014 compliance report IEC 61000-4-30 class S power quality measurement up to the 63rd harmonic harmonic distortion waveform capture voltage sag and swell detection programmablity (logic and math functions) IEC 62586 power quality monitoring disturbance direction detection rapid voltage change |
| Device Application | Power monitoring WAGES metering |
| Type of measurement | Current Voltage Frequency Active and reactive power total Apparent power total Power factor total Active and reactive power per phase, rms Apparent power per phase, rms Power factor per phase, rms |
| supply voltage | 90...415 V AC 45...65 Hz +/- 10 % 110...415 V DC +/- 10 % |
| Network Frequency | 50 Hz 60 Hz |
| Line Rated Current | 1 A 5 A 10 A |
| Poles description | 3P + N 3P 1P + N |
| Power Consumption in VA | 16 VA 230 V AC |
| Display Type | Colour TFT LCD |
| Display Resolution | 320 x 240 pixels QVGA |
| Sampling rate | 256 samples/cycle |
| Measurement current | 50â¦10000 mA |
| Analogue input type | Voltage (impedance 5 MOhm) Current (impedance 0.3 mOhm) |
| Measurement voltage | 57â¦400 V AC 42...69 Hz between phase and neutral 100â¦690 V AC 42...69 Hz between phases |
| Frequency measurement range | 42â¦69 Hz |
| Number of inputs | 3 digital 30 V AC 3 digital 60 V DC |
| Measurement accuracy | Current +/- 0.1 % Voltage +/- 0.1 % Active energy +/- 0.2 % |
| Accuracy class | Class 0.2S active energy IEC 62053-22 Class 0.2 active energy ANSI C12.20 Class 0.2 active power IEC 61557-12 Class 0.5S reactive energy IEC 62053-24 Class 0.5 power factor IEC 61557-12 Class 0.2 voltage IEC 61557-12 Class 0.2 current IEC 61557-12 |
| Number of Outputs | 1 pulse |
| Information displayed | Voltage Current Frequency Power Energy consumption Harmonic distortion |
| Communication port protocol | Modbus RTU 115 kbauds - 2-wire ION 115 kbauds - 2-wire DNP3 IEC 61850 Modbus TCP/IP Ethernet Modbus TCP/IP daisy chain 10/100 Mbit/s RSTP 801.1d 2004 |
| Communication port support | ETHERNET Screw terminal block RS485 |
| Communication Network Type | IPv6 (internet protocol) |
| Data recording | Min/max of instantaneous values Waveform logs Sequence of event recording Time stamping Alarm logs Trending/forecasting Sag and swell logs Harmonics logs GPS synchronisation Data logs Event logs 50 data recorders |
| Memory capacity | 512 MB |
| Web services | Customizable home page File upload/download via FTP File upload/download via SFTP Web server Alarm notification by e-mail Viewing of captured waveform (FTP) Viewing of captured waveform (web) HTTPS server |
| Communication Service | SMTP e-mail notification RSTP support NTP time synchronization DHCP PTP time synchronization |
| Cybersecurity | Enable/disable communication ports Password protection Syslog protocol support Robust security logs Port hardening |
| Mounting Mode | Flush-mounted |
| Mounting support | Framework |
| Installation category | III |
| Safety Construction | III400â¦690 V conforming to IEC 61010-1:ed. 3 III400â¦690 V conforming to EN 61010-1:ed. 3 III347â¦600 V conforming to UL 61010-1:ed. 3 III347â¦600 V conforming to CSA C22.2 No 61010-1:ed. 3 |
| Standards | IEC 61557-12 IEC 62052-11 IEC 62053-24 IEC 62053-22 IEEE 1588 IEC 62586-2 IEC 61326-1 |
| Product certifications | CE CULus N998 |
| Width | 3.8 in (96 mm) |
| Depth | 3.05 in (77.5 mm) |
| Height | 3.8 in (96 mm) |
| Product Weight | 20.5 oz (581 g) |
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Modicon Quantum |
| Product or Component Type | Ethernet RIO head for Quantum |
| Number of port | 4 |
| Integrated connection type | Ethernet IP/Modbus TCP service port Ethernet IP/Modbus TCP interlink port Ethernet IP/Modbus TCP device network |
| Communication Port Protocol | Ethernet IP/Modbus TCP |
| Communication Service | Diagnostics for remote I/O devices Configure IP parameters RSTP support Configuration for remote I/O devices Allows PLC to connect to an Ethernet network |
Complementary
| Characteristic | Value(s) |
|---|---|
| Topology | Daisy chain loop |
| Local signalling | 1 LED (green) for activity 1 LED (green) for ready 1 LED (green/red) for module status (Mod Status) 1 LED (green/red) for network communication status (Net Status) |
| Product Compatibility | 140CPU65150 140CPU65260 140CPU65160 140CPU67261 140CPU67160 |
| Environmental characteristic | Standard environment Hazardous location class I division 2 EN/IEC 61131-1 |
| Width | 6.6 in (167 mm) |
| Height | 2.0 in (50 mm) |
| Product Weight | 1.221 lb(US) (0.554 kg) |
Variable Speed Drive Altivar ATV312 - 7.5kW - 18kVA - 269W - 380..500 V - 3-Phase Supply
This Lexium 32 Servo Drive Works At A Rated Supply Voltage From 208Vac To 480Vac. It Can Feed 3-Phase Synchronous Motors Bmh Or Bsh, Its Continuous Output Current Is 6A At 8Khz. The Compact Size Of The Servo Drive And Associated Servo Motor Provides Maximum Power In The Minimum Space. This Servo Drive Is Specifically Designed For Industrial Machines. It Offers High Performance, Power And Simplicity Of Use In Motion Control Applications. It Complies With International Standards Iec/En 61800-5-1, Iec/En 61800-3, And Is Ul And Csa Certified And Ce Marked. It Has Been Developed To Meet The Requirements Of Directives Regarding Protection Of The Environment (Rohs).
This Lexium 32 Servo Drive Works At A Rated Supply Voltage From 208V Ac To 480V Ac. It Can Feed 3-Phase Synchronous Motors Bmh Or Bsh, Its Continuous Output Current Is 10A At 8Khz. The Compact Size Of The Servo Drive And Associated Servo Motor Provides Maximum Power In The Minimum Space. This Servo Drive Is Specifically Designed For Industrial Machines. It Offers High Performance, Power And Simplicity Of Use In Motion Control Applications. It Complies With International Standards Iec/En 61800-5-1, Iec/En 61800-3, And Is Ul And Csa And Is Ul And Csa Certified And Ce Marked. It Has Been Developed To Meet The Requirements Of Directives Regarding Protection Of The Environment (Rohs).
Variable Speed Drive Altivar ATV312 - 5.5kW - 15kVA - 232W - 380..500 V - 3-Phase Supply
Advanced touchscreen panel 800 x 600 pixels SVGA- 12.1" TFT - 96 MB
advanced touchscreen panel 640 x 480 pixels VGA- 10.4" TFT - 96 MB
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Modicon Quantum automation platform |
| Product or Component Type | Unity processor |
Complementary
| Characteristic | Value(s) |
|---|---|
| Mode of Transmission | Multi mode |
| Clock frequency | 266 MHz |
| Number of slots | 2 10 16 4 6 |
| Number of racks | 2 - local |
| Number of distributed I/O station | 63 1 3 Modbus Plus |
| Number of remote I/O station | 31 - 2 S908 remote I/O 31 - 2 ethernet Quantum remote I/O 16 - 2 ethernet X80 remote I/O |
| Discrete I/O number | 31744 inputs, 31744 outputs - remote 8000 inputs, 8000 outputs - distributed - per network Modbus Plus Unlimited (31 drops of 28 slots max) - ethernet remote I/O 0 - local - forbidden in Hot Standby application |
| Analogue I/O number | 500 inputs, 500 outputs - distributed - per network Modbus Plus Unlimited (31 drops of 28 slots max) - ethernet remote I/O 1984 inputs,1984 outputs - remote 0 - local - forbidden in Hot Standby application |
| Application specific I/O | High-speed interrupt inputs Serial link Accurate time stamping Counter |
| Communication Service | Ethernet router |
| Number of optional modules | 6 Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max) |
| Maximum number of connections | 1 USB 2 AS-Interface - distributed 4 AS-Interface - remote 6 Ethernet TCP/IP - local 6 Modbus Plus - local 6 Profibus DP - local 1 Modbus RS232/485 Modbus/ASCII) |
| Integrated connection type | 1 Modbus Plus 1 Modbus 1 USB 1 optic fibre Hot Standby |
| Checks | Process control Hot standby |
| Memory description | Expandable 7168 kB - program with PCMCIA card Expandable 8 MB - file storage with PCMCIA card Internal RAM 1024 kB - 512 kB for data |
| Switch Function | Key switch memory port on/off |
| Application structure | 1 periodic fast task - forbidden in Hot Standby application 128 I/O interrupt tasks - forbidden in Hot Standby application 128 interrupt tasks - forbidden in Hot Standby application 32 timer interrupt tasks - forbidden in Hot Standby application 4 auxiliary tasks - forbidden in Hot Standby application 1 cyclic/periodic master task - |
| Number of instructions per ms | 10.28 Kinst/ms 100 % Boolean 10.07 Kinst/ms 65 % Boolean and 35 % numerical |
| System overhead | 0.2 ms fast task 1 ms master task |
| Bus current requirement | 2500 mA |
| Local signalling | 1 LED (green) for Ethernet activity (COM) 1 LED (red) for Ethernet collision |
| Electrical connection | 1 female connector SUB-D 9 for connecting to the Modbus Plus network 1 connector RJ45 for connecting Modbus bus 1 connector MT-RJ (multimode fiber optic) for interconnecting primary and secondary PLCs up to 4 km |
This product is part of Modicon M340 range, a mid-range PAC for industrial process and infrastructure control. This communication module enables M580 and M340 platforms to use RTU protocol exchange with RTU stations. It is an RTU module with a current consumption of 95mA at 24V DC, work with internal power supply. This ruggedized product can be used in more severe environments, and operate in an extended temperature range, from -25°C to +70°C. It is furnished with Ethernet RJ45 10/100Mbps and serial RS232/485 RJ45 300/38400bps 1 twisted pair transparent ready class C30 for integrated connections. It is an IP20 rated product. It weighs 0.2kg. It is suitable for standard and severe environment applications. This product is certified by CE and UL. It meets UL 508, EN 61131-2, EN 61000-6-4, EN 61000-6-2 and EN 61010-2-201 standards. This module is compatible with Modicon M340 Programmable Logic Controllers (PLC). It is supplied with flash SD memory card (BMXRWS128MWF) 128000kB. It occupies one slot on the rack. Modicon X80 is a platform of modules common to Modicon M580 and M340 automation platforms that reduces maintenance and training costs with same spare parts in stock, and unique training for various Programmable Automation Controllers (PAC). Compact-shaped, Modicon M340 offers flexibility and integrated functions in a small box.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Modicon M340 |
| Product or Component Type | Communication module |
| Integrated connection type | Ethernet RJ45 10/100 Mbit/s 1 twisted pair transparent ready class C30 Serial RS232/485 RJ45 300/38400 bit/s 1 twisted pair transparent ready class C30 |
| Protective treatment | Conformal coating |
Complementary
| Characteristic | Value(s) |
|---|---|
| Communication service | Bandwidth management Modbus TCP messaging DNP3/DNP3 IP protocol IEC 60870-5 -101/-104 protocol Time stamped events management External modem management (serial, PSTN, GSM, GPRS/3G) Data logging in CSV files Email/SMS notifications Web server, rack viewer, data editor BootP, DHCP, FDR client SMTP server, FTP client/server, NTP client, SNMP agent, Automatic events backup on power loss Multi-protocols support in a single module (master and slave) Transparent events routing from remote slaves to SCADA |
| Port Ethernet | 10BASE-T/100BASE-TX |
| Memory description | Supplied Flash SD memory card (BMXRWS128MWF) 128000 kB |
| Memory usage | Activating the standard web server User web pages storage Data logging CSV files storage |
| Supply | Internal power supply via rack |
| Local signalling | 1 LED (green) for activity on Ethernet network (ETH ACT) 1 LED (green) for processor running (RUN) 1 LED (green) for status of Ethernet network (ETH STS) 1 LED (red) for memory card fault (CARD ERR) 1 LED (red) for processor or system fault (ERR) 1 LED (red) for download in progress (DL) 1 LED (yellow) for serial communication (SER COM) 1 LED (green) for data rate (ETH LINK) |
| Current consumption | 95 mA 24 V DC |
| Module format | Standard |
| Product Weight | 0.4 lb(US) (0.2 kg) |
distributed analog/discrete I/O Modicon Momentum
This Magelis GTO IP65 touchscreen operator interface (HMI) is supplied with 24V DC, has a 7" color TFT LCD display, 800 x 480 pixels (WVGA), 8 function keys and 96MB EPROM. This touchscreen operator interface (HMI) is ideal for optimized information and communication. Ideal for optimized information and communication with automation systems in industry and infrastructure such as compact machines, handling systems, food & beverage machines and pharmaceutical industry. The screen displays text messages, graphic objects and mimic diagrams, control and configuration of data. RS485 host port, ideal to supervise and control simple systems and machines. It is easily programmable with Vijeo Designer, with almost not coding needed.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony GTO |
| Product or Component Type | Advanced touchscreen panel |
| Display colour | 65536 colours |
| Display size | 7 inch |
| Supply | External source |
| Control Button Type | 8 operation defined using Vijeo Designer push-button key F1...F8 |
| Operating System | Harmony |
| Battery type | Lithium internal RAM 100 days 5 day(s) 10 year(s) |
Complementary
| Characteristic | Value(s) |
|---|---|
| Terminal type | Touchscreen display |
| Display Type | Backlit colour TFT LCD |
| Display Resolution | 800 x 480 pixels WVGA |
| Touch sensitive zone | 1024 x 1024 |
| Touch panel | Resistive film, 1000000 cycles |
| Backlight lifespan | 50000 hours white 77 °F (25 °C) |
| Brightness | 16 levels by touch panel 16 levels by software |
| Character font | Taiwanese (traditional Chinese) ASCII Chinese (simplified Chinese) Japanese (ANK, Kanji) Korean |
| [Us] rated supply voltage | 24 V DC |
| Supply voltage limits | 19.2â¦28.8 V |
| Inrush current | 30 A |
| Maximum power consumption in W | 8 W when power is not supplied to external devices 5 W when backlight is OFF 5.5 W when backlight is dimmed 12 W |
| Local signalling | Status LED green, steady offline Status LED green, steady operating Status LED orange, flashing software starting up Status LED red, steady power supply (ON) Status LED clear, faded power supply (OFF) COM2 LED yellow, steady data is being transmitted COM2 LED yellow, faded no data transmission SD card LED green, steady card is inserted SD card LED green, faded card is not inserted or is not being accessed |
| Software designation | Vijeo Designer configuration software >= V6.1 |
| Memory description | Flash EPROM, 96 MB |
| Data backed up | 128 kB internal RAM SRAM) |
| Data storage equipment | SD card, <= 32 GB SDHC card, <= 32 GB |
| Downloadable protocols | Schneider Electric Modicon Modbus Schneider Electric Modicon Uni-TE Schneider Electric Modicon Modbus Plus Schneider Electric Modicon FIPWAY Mitsubishi Melsec third party protocols Omron Sysmac third party protocols Rockwell Automation Allen-Bradley third party protocols Siemens Simatic third party protocols Schneider Electric Modicon Modbus TCP |
| Integrated connection type | COM1 serial link SUB-D 9 RS232C 2400...115200 bps COM2 serial link RJ45 RS485 2400...115200 bps COM2 serial link RJ45 RS485 187.5 kbps Siemens MPI Ethernet RJ45 10BASE-T/100BASE-TX Ethernet RJ45 IEEE 802.3 USB 2.0 type A USB 2.0 type mini B |
| Product mounting | Flush mounting |
| Fixing mode | by 4 screw clamps |
| Front material | PPT |
| Enclosure Material | PPT |
| type of cooling | Natural convection |
| Width | 8.6 in (218 mm) |
| Height | 6.8 in (173 mm) |
| Depth | 2.4 in (60 mm) |
| Product Weight | 2.6 lb(US) (1.2 kg) |
Unity processor - 8 racks (12 slots) / 16 racks (4/6/8 slots) - 1650 mA, 5 V DC
Schneider Electric is a global manufacturer of industrial automation and energy management solutions, including Modicon PLC platforms, EcoStruxure™ automation architecture, industrial HMIs, Altivar drives, motor control components, and power distribution systems. Schneider Electric technologies support scalable PLC-based machine control, process automation, and plant-wide energy integration across manufacturing, utilities, infrastructure, and industrial environments.
PLC Direct supplies Schneider PLC hardware, automation components, and industrial control parts supporting installed Schneider systems. Our Schneider collection serves customers sourcing replacement Modicon PLC modules, HMIs, drives, and Schneider Electric parts to maintain operational continuity within existing automation environments.
Why Choose Schneider Electric: Integrated PLC Control and Energy Management
Schneider Electric combines PLC control platforms, industrial communication, motor control, and energy management within unified automation architectures. Through Modicon PLC systems and EcoStruxure™ architecture, Schneider integrates machine-level control with plant-wide monitoring and operational visibility.
Schneider Electric PLC and automation systems are commonly deployed in:
- Manufacturing automation and machine control
- Water and wastewater treatment facilities
- Food and beverage production lines
- Oil and gas operations
- Power generation and energy distribution
- Packaging and material handling systems
- Infrastructure and building automation
- Process industries requiring integrated control and energy oversight
This broad deployment reflects Schneider Electric’s specialization in scalable PLC platforms, industrial networking, and energy-aware automation environments.
Schneider Electric Products and Solutions
Schneider Electric organizes its automation portfolio around PLC platforms, visualization systems, drive technologies, industrial communication infrastructure, motor control hardware, and energy management devices. The Schneider collection at PLC Direct focuses on hardware supporting Schneider systems in place for maintenance, replacement, and lifecycle continuity.
Schneider Electric Product Families
Schneider Electric’s automation portfolio includes:
- Modicon PLC Platforms: Modicon M221, M241, M251, M340, M580, and Quantum PLC systems designed for machine automation and process control. These platforms support Ethernet-based communication, distributed I/O architectures, and scalable system configurations.
- EcoStruxure™ Automation Architecture: An integrated framework combining PLC control, industrial networking, SCADA connectivity, and energy management within unified automation environments.
- HMI and Visualization Systems: Magelis and Harmony operator panels designed for machine-level monitoring and operator interaction within Schneider PLC systems.
- Variable Speed Drives and Motion Control: Altivar variable frequency drives (VFDs), servo drives, and motion control hardware supporting motor regulation and synchronized machine applications.
- Motor Control and Electrical Components: Contactors, motor starters, relays, and circuit protection devices supporting automation and power distribution systems.
- Industrial Communication and Networking: Communication modules and networking hardware supporting Modbus TCP/IP, EtherNet/IP, and other industrial protocols (model-dependent).
- Power Monitoring and Energy Management Devices: Power meters, protection relays, and monitoring systems integrated within industrial control environments.
Schneider Electric Products Available on PLC Direct
Schneider Electric products available through PLC Direct's collection include:
- Modicon PLC controllers and expansion modules
- Industrial HMI panels and operator interfaces
- Altivar drives and motion control hardware
- Communication modules and networking components
- Motor control and electrical control devices
- Replacement Schneider Electric PLC-integrated modules for installed systems
These products are sourced for repair, replacement, and lifecycle support of existing Schneider Electric automation systems.
Lifecycle Support for Schneider Electric Automation Systems
PLC Direct supports Schneider Electric automation systems by supplying inventory-backed hardware across multiple stages of the system lifecycle. Our focus centers on helping customers maintain operational continuity within installed Modicon PLC, Altivar drive, and Schneider industrial control environments. PLC Direct operates as an independent Schneider supplier supporting installed automation systems.
Lifecycle-focused support includes:
- Schneider Electric inventory supporting deployed PLC platforms
- Replacement Schneider PLC hardware for installed systems
- Availability of select legacy and discontinued Schneider Electric parts
- Drive systems and motor control components supporting ongoing operations\
- Communication modules supporting established PLC architectures
Additional support may include:
- Stock-backed availability for replacement needs
- Assistance in locating difficult-to-source legacy Schneider products
- Support with part number identification and compatibility verification
- 1-year warranty coverage on supplied products
PLC Direct supplies Schneider Electric automation hardware for replacement and maintenance purposes and does not provide system design, programming, or integration services.
Frequently Asked Questions
1. What types of Schneider Electric parts does PLC Direct carry?
PLC Direct carries Schneider Electric parts, including Modicon PLC controllers, HMI panels, Altivar drives, communication modules, and motor control components used within installed automation systems.
2. Is PLC Direct an authorized Schneider distributor?
PLC Direct is an independent Schneider supplier of automation components. We provide surplus sealed and refurbished Schneider Electric hardware backed by our 1-year warranty to support maintenance and lifecycle requirements.
3. Does PLC Direct provide technical support for Schneider PLC systems?
PLC Direct is a hardware supplier and does not provide programming, configuration, troubleshooting, or system integration services. We can assist with part number identification and compatibility verification.
4. What is a Schneider Electric PLC?
A Schneider Electric PLC is a programmable logic controller within the Modicon platform used for machine automation, process control, and industrial system management.
5. Where can I find replacement Schneider PLC modules and parts?
PLC Direct specializes in sourcing replacement Schneider Electric PLC modules and automation hardware supporting installed industrial systems, including select discontinued products.
