The SICK WL9L-3P3432 is a compact photoelectric retro-reflective sensor utilizing autocollimation technology with a Class 1 visible red laser light source. Designed for detecting small objects without the need for a separate reflector, this sensor operates on the principle of minimum distance autocollimation with coaxial optics. It features a single teach-in button for easy configuration and offers light/dark switching modes. The sensor is housed in a rectangular VISTAL plastic enclosure with PMMA optics material and provides PNP complementary switching output. With IP66, IP67, and IP69K protection ratings, it is suitable for demanding industrial automation applications including packaging, material handling, and manufacturing processes where precise detection of small objects is required.
Item Details
- Brand Name: SICK
- Manufacturer: SICK AG
- Item Type Name: Photoelectric Retro-Reflective Sensor
- Product Family / Series: W9L-3
- Part Number: WL9L-3P3432
- Order Code: 1058176
Product Specifications
- detection_principle: Photoelectric retro-reflective sensor, autocollimation
- sensing_range: 0 to 12 m
- light_source: Visible red laser
- wavelength: 650 nm
- laser_class: Class 1
- supply_voltage: 10-30 V DC
- switching_output: PNP complementary output
- output_current: 100 mA
- switching_mode: Light/dark switching
- switching_frequency: 1 kHz
- adjustment_method: Single teach-in button
- connection_type: Cable with M12 male connector, 4-pin, 120 mm
- housing_material: VISTAL plastic
- optics_material: PMMA plastic
- cable_material: PVC
- protection_rating: IP66, IP67, IP69K
- mounting_hole: M3
- light_spot_diameter: 1 mm
- housing_design: Rectangular
Additional Details
- Protection Functions: Reverse polarity, Short-circuit, Interference suppression
- Polarization Filter: Yes
Measurements
- Dimensions: 12.2 mm x 50 mm x 23.6 mm (W x H x D)
