The Festo VUVG-L14-P53C-T-G18-1P3 is a 5-port, 3-position pneumatic solenoid valve with mid-position closed configuration from the VUVG series. This electrically actuated valve features a 14 mm piston spool design with mechanical spring reset operation, providing monostable functionality. The valve is pilot-controlled and rated for compressed air applications in accordance with ISO 8573-1:2010 [7;4;4] standards. It offers G1/8 threaded pneumatic connections and includes non-detenting, detenting, and covered manual override options. The unit is equipped with an electrical connection box for 24V DC operation with 1.0W coil power consumption. The valve housing is constructed from wrought aluminum alloy with HNBR/NBR seals, providing robust performance in industrial automation applications. IP40/IP65 protection ratings ensure reliable operation in demanding environments. Suitable for directional control in pneumatic systems, material handling, and general automation applications.
Item Details
- Brand Name: Festo
- Manufacturer: Festo
- Item Type Name: Pneumatic Solenoid Valve
- Product Family / Series: VUVG Series
- Manufacturer Part Number: 566501
- Valve Function: 5/3 Mid-Position Closed
- Actuation Type: Electrical
- Valve Design: Piston Spool Valve
- Reset Mechanism: Mechanical Spring Reset
- Pilot Type: Internal Pilot Air Supply
- Sealing Principle: Soft Sealing
- Manual Override: Non-detenting/Detenting/Covered
Product Specifications
- valve_size: 14 mm
- nominal_flow_rate: 620-650 L/min
- operating_pressure: 3-8 bar
- coil_voltage: 24 V DC
- coil_power_consumption: 1.0 W
- pneumatic_connections: G1/8 (5 ports)
- electrical_connection: Electrical connection box, 3-pin M8 plug (A-coded)
- protection_rating: IP40/IP65
- housing_material: Wrought Aluminum Alloy
- seal_material: HNBR/NBR
Additional Details
- Certifications / Approvals: C UL us - Recognized (OL), RCM trademark approval
- Mounting Type: Through-hole mounting
- Operating Temperature: -5°C to +50°C
- Medium: Compressed air (ISO 8573-1:2010 [7;4;4])
Measurements
- Weight: 0.20 lbs (91 g)
