The SICK UM30-213113 is a cylindrical ultrasonic distance sensor designed for precise non-contact distance measurement in industrial automation applications. Utilizing time-of-flight ultrasonic technology at 200 kHz, it reliably detects natural objects, glass, liquids, and transparent foils independent of color, surface, or material properties. The sensor features an operating range of 200 mm to 1,300 mm with a limiting range of 2,000 mm and offers high accuracy of ±1% with internal temperature compensation. It provides dual analog output capability with automatic selection between 4-20 mA current output or 0-10 V voltage output depending on load conditions. The M30 cylindrical housing with nickel-plated brass construction is rated IP65/IP67 for harsh industrial environments. Additional capabilities include synchronization and multiplexing of up to 50 sensors, adjustable measurement filters, and teach-in functionality for flexible application configuration.
Item Details
- Brand Name: Sick
- Manufacturer: SICK AG
- Item Type Name: Ultrasonic Distance Sensor
- Product Family / Series: UM30
- Part Number: UM30-213113
- Manufacturer Part Number: 6036918
Product Specifications
- operating_range: 200 mm to 1,300 mm
- limiting_range: 2,000 mm
- resolution: ≥0.18 mm
- repeatability: ±0.15%
- measurement_accuracy: ±1%
- ultrasonic_frequency: 200 kHz
- response_time: 92 ms
- output_time: 23 ms
- analog_output_current: 4 mA to 20 mA (≤500 Ω load)
- analog_output_voltage: 0 V to 10 V (≥100,000 Ω load)
- output_resolution: 12 bit
- supply_voltage: 9 V to 30 V DC
- power_consumption: ≤2.4 W
- initialization_time: <300 ms
- temperature_compensation: Yes
- multifunctional_input: 1x MF
- connector_type: M12, 5-pin, male connector
- housing_material: Nickel-plated brass
- thread_size: M30 x 1.5
- enclosure_rating: IP65 / IP67
- protection_class: III
Additional Details
- Target Objects: Natural objects, glass, liquids, transparent foils
- Detection Principle: Time-of-flight ultrasonic
- Output Function: Automatic selection of analog current or voltage output dependent on load
- Indication: LED display, 2x LED
- Mounting Type: Cylindrical body with M30 thread
- Special Features: Teach-in of analog output, scaling of analog outputs, invertable analog output, synchronization of up to 50 sensors, multiplexing capability
Measurements
- Dimensions: 30 mm x 30 mm x 84 mm (W x H x D)
- Form Factor: Cylindrical
